TE Connectivity AMPMODU MOD II Series Straight Through Hole Pin Header, 8 Contact(s), 2.54 mm Pitch, 2 Row 826656-4
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 750V |
| Brand | TE Connectivity |
| Orientation | Straight |
| Current | 3A |
| Model | 826656-4 |
| Mount Type | Through Hole |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Brass |
| Series | AMPMODU MOD II |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -65°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 8 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Tail Pin Length | 3.2mm |
| Mating Pin Length | 5.8mm |
Key Features
- Features an unshrouded, straight orientation with two rows of contacts.
- Constructed from brass contacts with gold plating for enhanced conductivity and corrosion resistance.
- Housing made from durable polybutylene terephthalate suitable for industrial applications.
- Supports a current rating of 3A and voltage up to 750V.
- Operates reliably within a temperature range of -65°C to 105°C.
- Designed for through-hole mounting with solder termination type for secure assembly.
- Tail pin length of 3.2 mm with mating pin length of 5.8 mm facilitates connection integrity.
- Ideal for automotive controls, industrial and test equipment, computers, telecommunications, medical instruments, and storage equipment.
Product Description
TE Connectivity 826656-4 AMPMODU MOD II Series Straight Through Hole Pin Header is engineered for high-quality, reliable connections in a variety of industrial environments. Featuring 8 male contacts arranged in two rows with a 2.54 mm pitch, this unshrouded pin header supports board-to-board and wire-to-board connector systems.
Its brass contact material with gold plating ensures excellent electrical conductivity and corrosion resistance, while the polybutylene terephthalate housing provides durability and stability at high temperatures up to 105°C. The product is designed for through-hole mounting and solder termination, enabling secure and efficient PCB assembly.
This connector operates safely at voltages up to 750V and currents of 3A, making it well-suited for demanding applications including automotive control systems, industrial machinery, telecommunications, and medical equipment.
The tail pin length is 3.2 mm with a mating pin length of 5.8 mm, ensuring reliable mechanical and electrical engagement. Its versatile breakaway design allows customization of connector size as per design needs, saving time and labor during installation.
Unshrouded double row 2.54 mm pitch pin header. Brass contacts with gold plating for durability. Polybutylene terephthalate housing suitable for harsh environments. Current rating of 3A with voltage up to 750V. Temperature range from -65°C to 105°C operation.
Through-hole mounting with solder termination type. Ideal for automotive, industrial, telecommunications, and medical applications.
TE Connectivity AMPMODU MOD II connectors form a reliable and economical interconnect system widely used in automation and control applications. These pin headers provide consistent performance, ease of installation, and adaptability, making them a preferred choice for engineers and designers in electronics manufacturing.
Explore more advanced PCB connectors and headers by TE Connectivity at EnvMart to meet your industrial and commercial electronic assembly requirements.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a voltage rating of up to 750V.
It has a current rating of 3A.
The contacts are arranged with a pitch of 2.54 mm.
This model features 8 male contacts arranged in two rows.
The contacts are made from brass with gold plating, and the housing is constructed from polybutylene terephthalate.
It operates reliably within a temperature range of -65°C to 105°C.
This unit is designed for through-hole mounting with a solder termination type.
The tail pin length is 3.2 mm, while the mating pin length is 5.8 mm.
It is suitable for automotive controls, industrial machinery, telecommunications, and medical instruments.
It supports board-to-board and wire-to-board connector systems.
This model features an unshrouded design.
The country of origin for this product is India.
