TDK-Lambda DC/DC Converter, 24V Output Voltage, 1.25A Output Current, 76V Maximum Input Voltage, 18V Minimum CCG30-48-xxD
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | Converters / DC-DC Converters TDK-Lambda CCG30-48-xxD DC/DC Converter, 24V/ 1 |
| Brand | TDK-Lambda |
| Efficiency | 91% |
| Length | 25.4mm |
| Model | CCG30-48-xxD |
| Depth | 9.9mm |
| Gross Weight | 20g |
| Width | 25.4mm |
| Mount Type | PCB |
| Series | CCG30-48-xxD |
| Package Type | 1 x 1 in |
| Minimum Operating Temperature | 85°C |
| MTBF | 3191064h |
| Number of outputs | 2 |
| Ripple and Noise | 190mV |
| Maximum Output Power | 18W |
| Maximum Input Voltage | 76V dc |
| Standards/Approvals | UL, CE, CSA, EN, IEC, RoHS |
| Minimum Input Voltage | 18V |
| Output Voltage 1 | 24V |
| Output Current 1 | 1.25A |
| Isolation Voltage | 1.5kV dc |
Key Features
- The converter supports a maximum input voltage of 76V dc and a minimum input voltage of 18V dc.
- It is housed in a 1 x 1 inch metal package with six-sided shielding for reduced noise.
- The unit offers high efficiency of up to 91% ensuring low power loss during operation.
- Designed for wide operating temperature range, it supports up to 85 °C maximum temperature.
- Provides an isolation voltage of 1.5kV dc for safe electrical isolation.
- Ripple and noise levels are maintained under 190mV for stable output.
- Mounting type is PCB, suitable for compact electronic assembly applications.
- MTBF (Mean Time Between Failures) is 3,191,064 hours ensuring long service life.
Product Description
TDK-Lambda CCG30-48-12D DC/DC Converter is a high-quality power supply component designed for electronic applications requiring stable 24V output with 1.25A current. This model features a compact 1 x 1 inch footprint and is suitable for PCB mounting, making it ideal for integration into various electronic circuits and devices.
The converter supports a wide input voltage range from 18V to 76V dc, allowing use in diverse power environments. With a maximum output power of 18W and efficiency of up to 91%, it delivers reliable performance with minimal energy losses.
Encased in a metal enclosure with six-sided shielding, the device provides excellent noise reduction and robust protection against shock and vibration, suitable for industrial and commercial electronics manufacturing, laboratory equipment, and telecommunications systems.
Operating temperature ranges from -40 °C to 85 °C, the converter is built to withstand demanding environmental conditions. The isolation voltage rating of 1.5kV dc ensures safety and compliance with relevant electrical standards including UL, CE, CSA, EN, IEC, and RoHS.
The minimal ripple and noise of 190mV guarantee clean power output critical for sensitive electronic components. Its MTBF of over 3 million hours underlines the product’s durability and reliability in continuous use.
The converter supports input voltage ranges of 18V to 76V dc. Output voltage is fixed at 24V with a current capacity of 1.25A. Package size is 25.4mm x 25.4mm x 9.9mm, fitting standard 1 x 1 inch footprint assemblies. Designed for PCB mounting with metal casing and noise shielding.
Efficiency reaches up to 91% to optimize energy use. Complies with UL, CE, CSA, EN, IEC, and RoHS standards. Suitable for industrial, laboratory, telecommunications, and manufacturing applications.
This TDK-Lambda DC/DC Converter model CCG30-48-12D is principally used where stable DC voltage conversion is required for industrial electronics, control systems, and embedded power modules. Its rugged design and certification ensure dependable performance in demanding electrical engineering projects.
Explore a broad range of DC/DC Converters and power supplies here at EnvMart to find compatible components tailored for your technical requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model provides a fixed output voltage of 24V and an output current of 1.25A.
The converter supports a maximum input voltage of 76V dc and a minimum input voltage of 18V dc.
It has an efficiency rating of up to 91%, ensuring low power loss during operation.
The converter has dimensions of 25.4mm x 25.4mm x 9.9mm, fitting a standard 1 x 1 inch footprint.
The isolation voltage rating is 1.5kV dc, providing safe electrical isolation.
It operates within a temperature range of -40 °C to 85 °C.
The ripple and noise levels are maintained under 190mV, ensuring stable output.
This model is designed for PCB mounting, suitable for compact electronic assemblies.
The MTBF is rated at 3,191,064 hours, indicating a long service life.
It complies with UL, CE, CSA, EN, IEC, and RoHS standards.
The maximum output power is 18W, allowing it to meet various power requirements.
It is suitable for industrial electronics, control systems, and embedded power modules.
