TDK B82477-G4 Shielded Wirewound Surface Mount Inductor with Ferrite Core 68μH ±20% 2.1A DC Current B82477G4683M000
Specifications
| Country of Origin | India |
|---|---|
| Brand | TDK |
| Height | 8mm |
| Length | 12.8mm |
| Model | B82477G4683M000 |
| Depth | 12.8mm |
| Packaging | Tape & Reel |
| Series | B82477-G4 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Core Material | Ferrite |
| Inductance | 68μH |
| Standards/Approvals | RoHS |
| Maximum DC Current | 2.1A |
| Pin Count | 2 |
| Maximum DC Resistance | 120mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Solder |
| Inductor Construction | Wirewound |
Key Features
- Magnetically shielded ferrite core reduces electromagnetic interference.
- Wirewound construction ensures stable inductance and durability.
- Suitable for filtering supply voltages and DC-DC converter applications.
- Operates safely between -55°C and 125°C temperatures.
- Solder termination style designed for surface mounting.
- Compact dimensions with length 12.8mm, height 8mm, and depth 12.8mm.
- Low maximum DC resistance of 120 milliohms for efficient current flow.
- Compliance with RoHS standards ensures environmental safety.
Product Description
TDK B82477G4683M000 is a magnetically shielded wirewound surface mount inductor featuring a ferrite core, designed for electronic applications requiring stable inductance and low electromagnetic interference. With an inductance of 68 microhenries and tolerance of ±20%, this inductor supports a maximum DC current of 2.1 amperes, making it suitable for use in power supply filtering, DC-DC converters, and automotive electronic circuits.
The component operates reliably across a temperature range of -55°C to 125°C, ensuring durability in diverse industrial environments. Its compact size (length 12.8mm, height 8mm, depth 12.8mm) allows for efficient use of PCB space, while the solder termination style facilitates secure surface mounting.
The wirewound construction with a ferrite core contributes to low DC resistance (maximum 120 milliohms), aiding in efficient current conduction and minimizing energy loss. The shielding feature reduces electromagnetic interference, critical for maintaining signal integrity in sensitive electronic devices.
This part complies with RoHS standards, reflecting environmentally responsible manufacturing. Packaged in tape and reel format, it supports high-volume automated assembly processes to improve production efficiency.
Magnetically shielded ferrite core reduces electromagnetic interference. Wirewound construction provides stable inductance and durability. Operating temperature range from -55°C to 125°C suits industrial applications. Maximum DC current rating of 2.1 amperes supports moderate power circuits.
Low maximum DC resistance of 120 milliohms reduces power losses. Compact dimensions facilitate PCB design optimization. RoHS compliant for environmental safety and regulatory adherence. Available in tape and reel packaging suitable for automated manufacturing.
Solder termination style ensures reliable surface mounting. Two-pin design for ease of circuit integration.
This Surface Mount Inductor is ideal for industrial electronics, automotive systems, power supplies, filtering circuits, and manufacturing requiring compact, reliable inductors with shielding for EMI reduction. Explore more high-quality inductors and electronic components in our Electronics Components category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this inductor is 68 microhenries (μH) with a tolerance of ±20%.
This model supports a maximum DC current of 2.1 amperes.
It operates reliably within a temperature range of -55°C to 125°C.
The inductor has compact dimensions of 12.8mm in length, 8mm in height, and 12.8mm in depth.
This inductor features a ferrite core, which helps in reducing electromagnetic interference.
The maximum DC resistance is 120 milliohms, which aids in efficient current flow.
It uses a solder termination style designed for surface mounting.
It is packaged in tape and reel format, which is suitable for automated assembly processes.
This inductor complies with RoHS standards, ensuring environmental safety.
It is suitable for applications such as power supply filtering, DC-DC converters, and automotive electronic circuits.
This inductor has a two-pin design for ease of circuit integration.
This inductor belongs to the B82477-G4 series.
