Bourns Wirewound Shielded Surface Mount Inductor 22 μH ±30%, 2.2 A DC, Ferrite Core, 1038 Package SRU1038
Specifications
| Country of Origin | India |
|---|---|
| Brand | Bourns |
| Height | 3.8mm |
| Length | 10mm |
| Model | SRU1038 |
| Depth | 10mm |
| Packaging | Reel |
| Series | SRU1038 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 22μH |
| Standards/Approvals | RoHS |
| Package/Case | 1038 |
| Maximum DC Current | 2.2A |
| Maximum DC Resistance | 55.8mΩ |
| Inductance Tolerance | ±30 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 12MHz |
| Minimum Quality Factor | 20 |
| Inductor Construction | Wirewound |
Key Features
- Features a ferrite core for enhanced magnetic properties.
- Maximum DC current rating of 2.2 amps ensures reliable performance.
- Package size 1038 with dimensions of 10 mm length, 10 mm depth, and 3.8 mm height.
- Shielded wirewound construction reduces electromagnetic interference.
- Suitable for surface mount applications on printed circuit boards.
- Operates reliably between -40°C and 125°C operating temperature.
- Complies with RoHS standards for environmental safety.
- Maximum DC resistance of 55.8 milliohms minimizes power loss.
Product Description
Bourns SRU1038 is a wirewound shielded surface mount inductor designed with a ferrite core to provide stable inductance in electronic circuits. It offers an inductance value of 22 μH with a tolerance of ±30%, making it suitable for regulated power supplies and filtering applications.
The inductor supports a maximum DC current of 2.2 A and has a robust package size 1038, measuring 10 mm in length and depth with a height of 3.8 mm. The shielded construction minimizes electromagnetic interference, ensuring signal integrity in sensitive applications.
Operating temperature ranges from -40°C to 125°C, providing reliability in industrial and automotive electronics environments. The component complies with RoHS environmental and safety standards and features a low maximum DC resistance of 55.8 mΩ to reduce power losses.
With a minimum quality factor of 20 and a maximum self-resonant frequency of 12 MHz, this inductor is optimized for high-frequency power supply circuits, including DC/DC converters and other power management solutions.
Applications include use in industrial electronics, automotive control systems, and consumer electronics where surface mount reliability and performance are critical. Features a ferrite core for stable magnetic properties and shielding.
Maximum DC current rating of 2.2 A for high current applications. Compact 1038 package size optimized for surface mounting. Wide operating temperature range: -40°C to 125°C for versatile environments. RoHS compliant ensuring environmental safety compliance.
Low DC resistance at 55.8 mΩ for efficient power usage. High quality factor of 20 ensuring efficiency at relevant frequencies. Maximum self-resonant frequency of 12 MHz for high-frequency circuits. Wirewound construction offering durability and performance stability.
Ideal for DC/DC converters, power supplies, and automotive electronics. Explore more components like this in the Surface Mount Inductors category at EnvMart for advanced electronics design and manufacturing.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model features an inductance value of 22 μH with a tolerance of ±30%.
It supports a maximum DC current of 2.2 A, ensuring reliable performance in high current applications.
The inductor has a package size of 1038, measuring 10 mm in length, 10 mm in depth, and 3.8 mm in height.
It operates reliably within a temperature range of -40°C to 125°C, making it suitable for various environments.
The shielded wirewound construction minimizes electromagnetic interference, ensuring signal integrity in sensitive applications.
The maximum self-resonant frequency is 12 MHz, which is optimized for high-frequency power supply circuits.
It features a maximum DC resistance of 55.8 milliohms, which helps to minimize power loss.
Yes, this model complies with RoHS standards for environmental safety.
It is constructed with a ferrite core, which enhances its magnetic properties.
This inductor is suitable for use in industrial electronics, automotive control systems, and consumer electronics.
The minimum quality factor is 20, ensuring efficiency at relevant frequencies.
The termination style is surface mount, making it suitable for printed circuit board applications.
