WEG Thermal Overload Relay, DIN Rail, 1 NO/1 NC, 8A F.L.C, Adjustable 5.6–8A, 690V AC, 1.4 W, IP20/IP10, Automatic & RW17

Free Delivery in India | Lowest Global Shipping Charges

WEG Thermal Overload Relay, DIN Rail, 1 NO/1 NC, 8A F.L.C, Adjustable 5.6 - 8A, 690V AC, 1.4 W, IP20/IP10, Automatic & RW17



Category Overload Relays Brand WEG Condition New

Specifications

Country of Origin	Brazil
Brand	WEG
Length	71.5mm
Model	RW17
Depth	82.5mm
IP Rating	IP20, IP10
Width	45mm
Mount Type	DIN Rail
Series	RW17
Power Rating	1.4W
Maximum Operating Temperature	60°C
Minimum Operating Temperature	-25°C
Terminal type	Screw
Supply Voltage	100, 50V
Contact Voltage	690V ac
Reset Method	Automatic & Manual
Normal State Configuration	1 NO/1 NC
Relay Contact Current	5.6, 8A
Number of Auxiliary Contacts	2
Pole and Throw Configuration	3
FLC Motor Rating	8A
Adjustable Current Range	5.6 → 8 A

Key Features

Equipped with 1 normally open and 1 normally closed contact for versatile control.
Supports 8A full load current, suitable for a variety of motors.
Adjustable current range allows precision protection from 5.6A to 8A.
Features screw terminals for secure electrical connections.
Rated up to IP20/IP10 for increased safety against dust and accidental contact.
Operates over a wide temperature range from -25°C up to 60°C.
690V AC contact voltage and 1.4 W power rating ensure robust performance.
DIN rail mount for easy installation in control panels.

Product Description

WEG RW17-1D3-U008 Thermal Overload Relay combines robust protection and flexibility for industrial motor circuits. Featuring a compact form factor, this relay accommodates DIN rail installation and ensures precise protection for motors operating at full load currents up to 8A. With both automatic and manual reset modes, the RW17-Series relay adapts to a broad spectrum of safety and operational requirements.

Equipped with both 1 normally open (NO) and 1 normally closed (NC) auxiliary contact for diverse control strategies. Adjustable current range (5.6A - 8A) allows tuning to specific motor characteristics, securing enhanced operational safety.

Screw terminal connections facilitate straightforward, reliable wiring in industrial automation panels. Contact voltage rated at 690V AC and 1.4 W power rating deliver dependable switching for demanding applications. Protective enclosure rated IP20 and IP10 minimizes risk from dust and accidental electrical contact.

Operating temperature range from - 25°C to 60°C supports deployment in challenging environments. Automatic/manual reset options allow easy integration into different safety protocols. 3-pole configuration, phase failure sensitivity, and support of hand or automatic reset methods further enhance reliability.

Complies with EU Regulation 640/2009/EC, IEC 60947-4-1, IEC 60947-2, IEC 60947-1, IEC 60034-30-1, and Directive 2009/125/EC for high safety standards. Ideal for protecting industrial AC motors, manufacturing equipment, conveyor systems, and automation panels.

The RW17-1D3-U008 is particularly suitable for industrial environments that require high performance and adaptable protection for motor-driven devices. The relay's ability to respond to overload conditions and its versatile reset approach make it an essential safeguard for manufacturing, construction, HVAC and control panel assemblies.
