XP Power FS50P-12 Isolated DC/DC Converter, 5kV Output, 2mA Output Current, 12V DC Input, Through Hole, 10W

XP Power FS50P-12 DC/DC Converter is a robust isolated converter designed for applications requiring high-voltage DC output up to 5kV and precise 2mA output current. Engineered for electronic systems demanding efficiency and reliability, it accepts 12V DC input and delivers regulated output power up to 10W, making it suitable for instrumentation, test equipment, and laboratory hardware.

This converter features through hole mounting, facilitating easy integration into PCB designs and prototype boards. Its compact physical dimensions (57.15mm length, 28.5mm width, 12.7mm depth) and low gross weight (45g) support dense space-constrained layouts. Build quality is reinforced by an isolation voltage rated at 2.5kV, providing safety for operators and protection for sensitive electronics from voltage surges and spikes.

Operational efficiency stands at 85%, reducing power loss and minimizing heat generation. The converter maintains output ripple and noise below 2.5% peak-to-peak, which is critical for precision measurement and control circuits. It offers an output voltage adjustment range of ±3% to accommodate calibration or variable applications.

With an MTBF of 840,000 hours, this product delivers long-term reliability under continuous operation. Its wide operating temperature window (-25°C minimum to 75°C maximum) ensures stable performance across industrial, laboratory, and commercial settings.

Typical industrial uses include high-voltage test systems, precision electronic instrumentation, laboratory power supplies, and applications demanding high-voltage isolation. It is equally suitable for manufacturing quality control equipment, safety interlocks, and sensitive sensor systems requiring noise-resistant power.

XP Power's FS50P-12 is ideal for designers and engineers requiring dependable high-voltage conversion with through hole flexibility, supported by robust electrical and operational ratings.

Provides isolated DC to high-voltage DC conversion with 5kV output. Supports up to 2mA output current at maximum 10W output power. Accepts a stable 12V DC input for reliable operation. Through hole mounting ideal for PCB integration and prototyping.

85% typical efficiency ensures energy savings and heat reduction. Offers high isolation voltage rated at 2.5kV for enhanced safety. Features ripple and noise level of 2.5% peak-to-peak for sensitive circuits. Wide operating temperature range from -25°C to 75°C for versatile environments.

Compact form factor with dimensions 57.15mm x 28.5mm x 12.7mm and 45g weight. Discover more XP Power DC-DC Converters and high-voltage solutions in EnvMart's Electronics & Electricals portfolio.
