WEG CWC LINE Overload Relay, 2 NO/2 NC, 10A, 24V DC, DIN Rail Mount, CWCA0-22-00C03

Free Delivery in India | Lowest Global Shipping Charges

WEG CWC LINE Overload Relay, 2 NO/2 NC, 10A, 24V DC, DIN Rail Mount, CWCA0-22-00C03



Category Overload Relays Brand WEG Condition New

Specifications

Country of Origin	Brazil
Brand	WEG
Length	58mm
Model	CWCA0-22-00C03
Depth	52mm
IP Rating	IP20
Width	45mm
Mount Type	DIN Rail
Series	CWC LINE
Maximum Operating Temperature	55°C
Minimum Operating Temperature	-25°C
Terminal type	Screw
Supply Voltage	100, 50V
Contact Voltage	690V ac
Normal State Configuration	2 NO/2 NC
Relay Contact Current	10A
Number of Auxiliary Contacts	4
Pole and Throw Configuration	4
Control Voltage	24V dc
Eaton DILA Contactor, 24V dc Coil, 4-Pole, 4 A 24V dc, 2 NO/2 NC, 415V acBrand	Eaton
Lovato BG Contactor Relay, 24V dc Coil, 4-Pole, 10 A, 2 NO/2 NC, 690V acBrand	Lovato

Key Features

Features a 2 NO/2 NC contact setup for versatile control functionality.
Contacts rated to handle up to 10A for industrial electrical loads.
Suitable for DIN rail mounting for easy integration into control panels.
Wide operating voltage, supporting control voltage of 24V DC.
Compact (58mm × 45mm × 52mm) design saves panel space.
Built-in screw terminals ensure secure wiring connections.
IP20 enclosure for protection against finger contact and small tools.
Operational temperature range from -25°C to 55°C for demanding environments.

Product Description

The WEG CWCA0-22-00C03 Overload Relay is engineered for industrial protection and switching applications, delivering robust performance in control panels, automation systems, and motor circuits. It is part of the well-regarded CWC LINE series known for its modular and compact construction while maintaining exceptional reliability and electrical endurance.

This relay offers a 2 NO/2 NC configuration, making it flexible for both control and indication purposes. With a 10A contact rating, it handles substantial actuator and load switching duties in electrical circuits. The relay is suitable for DIN rail mounting and features convenient screw terminals that facilitate quick, secure connections during installation and maintenance.

The CWCA0-22-00C03 is built with an IP20 enclosure, protecting against inadvertent contact with live components and ensuring safety for both maintenance staff and equipment. Its compact form factor, measuring only 58mm in length, 45mm in width, and 52mm in depth, allows integration into dense control cabinets without consuming excessive space.

Supporting a 24V DC control voltage alongside a high switching voltage of up to 690V AC, the relay meets rigorous IEC and EN standards. Its ability to withstand an operational temperature from -25°C to 55°C extends its usage to challenging industrial and utility environments, ensuring reliable performance year-round.

This overload relay is ideally used for motor protection, circuit reliability, and automation projects in sectors such as manufacturing, process industries, utilities, and building automation. It is compatible with direct DIN rail or panel mounting and comes with built-in auxiliary contacts for enhanced versatility in system integration. The relay’s professional engineering delivers longevity and reduced downtime, fulfilling critical industrial requirements.

For more advanced overload and contactor solutions, browse the full range of WEG CWC LINE products and other specialized overload relays under EnvMart's comprehensive Electronics & Electricals → Relays & Contactors → Overload Relays category.
