Eaton xPole PXL Miniature Circuit Breaker, 1-Pole, 10A, Type D, 400V AC, 48V DC, 10kA, DIN Rail, IP20 236095 PXL-D10/1
Specifications
| Country of Origin | Austria |
|---|---|
| Range | xPole |
| Brand | Eaton |
| Height | 17.5mm |
| Model | 236095 PXL-D10/1 |
| Depth | 60mm |
| IP Rating | IP20 |
| Width | 80mm |
| Mount Type | DIN Rail |
| Current Rating | 10A |
| Series | PXL |
| Breaking Capacity | 10kA |
| Number of Poles | 1 |
| Standards/Approvals | EN 60898, IEC |
| Rated AC Voltage | 400V ac |
| Rated DC Voltage | 48V dc |
| Tripping Characteristics | Type D |
| Tripping Mechanism | Electromagnetic |
| Reset Actuator Type | Toggle Switch |
| Break Time | Instantaneous |
Key Features
- Reliable protection for industrial and commercial circuits.
- Suitable for 1-pole, 10A current load applications.
- Operates at 400V AC and 48V DC with Type D tripping.
- Instantaneous break time and electromagnetic mechanism.
- DIN rail mounting with double terminal configuration.
- Compact dimensions for easy panel integration.
- IP20 protection for finger-proof and secure installation.
- Compliant with EN 60898 and IEC standards.
Product Description
Eaton 236095 PXL-D10/1 Miniature Circuit Breaker is designed for the reliable protection of electrical circuits in industrial, commercial, and building installations. This single-pole circuit breaker operates at a rated current of 10A and is engineered to handle both 400V AC and 48V DC supplies, making it versatile across a wide range of applications.
The device utilizes Type D tripping characteristics, which are ideal for circuits with higher inrush currents. As part of the xPole PXL series, this circuit breaker delivers high selectivity as a pre-fuse and features low passband energy, ensuring sensitive protection against overloads and short circuits.
Installation is effortless thanks to its DIN rail compatibility. The double terminal design (lift/jaw top and bottom) simplifies wiring and allows flexible rail arrangement. The toggle switch actuator provides clear on/off status and easy reset, while the electromagnetic tripping mechanism ensures precise and instantaneous interruption when electrical faults occur.
Safety is enhanced by its IP20 protection rating, offering finger-proof and back-of-hand-proof construction, and a quick-fit action with three locking positions for secure mounting on IEC/EN 60715 top-hat rails. The breaker is compliant with EN 60898 and IEC standards, adhering to the rigorous requirements expected in modern electrical infrastructures.
With a breaking capacity of 10kA, the Eaton PXL-D10/1 guarantees reliable circuit interruption in demanding environments. The compact design (80mm wide, 60mm deep, 17.5mm high) ensures it fits easily in panels and distribution boards, while its instantaneous break time minimizes downtime during fault conditions.
Commonly used in industrial, commercial, HVAC, and automation systems, this MCB is suitable for bus bar arrangements and features finger-safe terminal access for safer installations and maintenance routines.
Explore Eaton’s full range of miniature circuit breakers and related electrical protection products at EnvMart, and discover high-performance solutions for your electrical safety needs.
Explore more products in our Miniature Circuit Breaker (MCB) category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 10A, making it suitable for 1-pole applications.
It operates at a rated voltage of 400V AC and 48V DC, allowing versatility in various electrical applications.
The breaking capacity of the Eaton PXL-D10/1 is 10kA, ensuring reliable circuit interruption during overloads and short circuits.
This circuit breaker utilizes an electromagnetic tripping mechanism, which provides instantaneous interruption during electrical faults.
It is designed for DIN rail mounting, which simplifies installation and allows for flexible rail arrangements.
This unit has compact dimensions of 80mm in width, 60mm in depth, and 17.5mm in height, facilitating easy integration into panels.
The Eaton PXL-D10/1 has an IP20 rating, providing protection against finger access and ensuring safe installation.
It complies with EN 60898 and IEC standards, meeting the rigorous requirements for modern electrical infrastructures.
It is commonly used in industrial, commercial, HVAC, and automation systems, providing reliable protection for electrical circuits.
The reset actuator type for the Eaton PXL-D10/1 is a toggle switch, which provides clear on/off status and easy reset functionality.
This model features Type D tripping characteristics, which are ideal for circuits with higher inrush currents.
The country of origin for this circuit breaker is Austria.
