United Automation Linear Voltage Regulator, 15A, 230V, Through Hole, 3-Pin, Adjustable CSR1504A
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Voltage | Regulators United Automation CSR1504A Linear, Voltage Regulator, 15 A, 230V 3-Pi |
| Brand | United Automation |
| Height | 29.3mm |
| Length | 17.5mm |
| Model | CSR1504A |
| Width | 7.6mm |
| Mount Type | Through Hole |
| Output type | Adjustable |
| Series | CSR1 |
| Output Current | 15A |
| Maximum Operating Temperature | 70°C |
| Minimum Operating Temperature | 0°C |
| Regulator Type | Linear |
| Maximum Input Voltage | 230V |
| Output Voltage | 230V |
| Pin Count | 3 |
Key Features
- Offers precise linear voltage regulation for single-phase mains loads.
- Delivers robust current capacity up to 15A with a maximum output voltage of 230V.
- Through hole mounting and a compact transistor-style housing for easy installation.
- Adjustable output and isolated heat sink tab for flexible integration.
- Ideal for controlling resistive and inductive loads such as heating elements, ovens, fans, and transformers.
- Operational across a broad temperature range of 0°C to 70°C for demanding environments.
- Features 3-pin design to accommodate common circuit layouts.
- Supports external 220 k or 250 k potentiometer (not supplied) for user-defined regulation.
Product Description
The United Automation CSR1504A is a high-performance linear voltage regulator engineered for precise control over AC loads in industrial, commercial, and laboratory environments. This regulator is designed to handle up to 15A output current at a maximum voltage of 230V, making it suitable for demanding power management applications. It is supplied in a compact transistor-style package with an isolated heat sink tab, which allows for effective thermal management and straightforward integration into circuit designs.
The CSR1504A enables the user to adjust output using an external linear potentiometer (220k or 250k, not included), providing control over power delivery from 0% to 98%. This flexibility makes it ideal for a wide array of resistive heating elements including ovens, dryers, and quartz lamps, as well as certain inductive loads like motors, fans, and transformers. It is particularly valued in machine automation, control systems, and process equipment, where precise regulation and compact design are paramount.
With a through-hole mounting style, this voltage regulator simplifies PCB assembly and enhances ruggedness for frequent use in industrial settings. The device operates reliably across a temperature span of 0°C to 70°C and includes inherent safety benefits due to its solid-state architecture. The adjustable output type ensures adaptability for different application needs, whether in prototyping, maintenance, or production-scale deployments.
Key technical features such as its 3-pin configuration, compact dimensions (17.5 mm length, 7.6 mm width, 29.3 mm height), and the ability to deliver high-precision voltage stabilization set the CSR1504A apart. Its design complies with modern industrial standards, supporting applications in industrial automation, laboratory instrumentation, HVAC, heating processes, and manufacturing control.
By integrating the United Automation CSR1504A Linear Voltage Regulator, engineers and system designers can ensure stable and adjustable voltage supply, protecting critical loads from power fluctuations and enhancing equipment longevity. This component is essential for reliable power management solutions in various sectors.
Browse more industrial Voltage Regulators and related control solutions by United Automation in the EnvMart platform to meet your technical requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The CSR1504A can deliver a maximum output current of 15A.
The maximum output voltage for this model is 230V.
This model features a through-hole mounting style, facilitating easy PCB assembly.
It operates reliably within a temperature range of 0°C to 70°C.
The dimensions of this unit are 17.5 mm in length, 7.6 mm in width, and 29.3 mm in height.
This regulator is suitable for controlling resistive and inductive loads, such as heating elements, ovens, fans, and transformers.
Yes, it supports an external linear potentiometer of 220k or 250k for user-defined regulation, which is not supplied with the unit.
This model has a 3-pin configuration, accommodating common circuit layouts.
The CSR1504A is a linear voltage regulator designed for precise control over AC loads.
The CSR1504A is manufactured in the United Kingdom.
This model is part of the CSR1 series of voltage regulators.
Using a linear voltage regulator provides stable and adjustable voltage supply, protecting critical loads from power fluctuations.
