TE Connectivity Mini-Universal MATE-N-LOK Series PCB Header, Straight Through Hole, 9 Contacts, 4.14 mm Pitch, 3 1-770182-0
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 600V |
| Brand | TE Connectivity |
| Orientation | Straight |
| Current | 9.5A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | Mini-Universal MATE-N-LOK |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 3 |
| Pitch | 4.14mm |
| Contact Plating | Tin |
| Number of Contacts | 9 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.69mm |
Key Features
- Mini-Universal MATE-N-LOK PCB header designed for wire-to-board connections.
- Provides 9 contacts in 3 rows with a 4.14 mm pitch for reliable circuit integration.
- Constructed with durable UL94V-0 nylon housing and tin-plated brass contacts.
- Includes a shrouded straight orientation and locking mechanism for secure mating.
- Mount type is through hole, suitable for solder termination on printed circuit boards.
- Supports up to 9.5A current and maximum operating voltage of 600V.
- Offers operational stability from -55°C to 105°C for harsh environments.
- Male contact gender with tail pin length of 3.69 mm for firm PCB retention.
Product Description
TE Connectivity 1-770182-0 Mini-Universal MATE-N-LOK Series PCB Header is engineered for demanding wire-to-board connections in industrial and electronic assembly applications. This straight through hole header features 9 contacts arranged in three rows, with a precise 4.14 mm pitch for compatibility with a wide range of PCB layouts.
Designed for reliability, the header incorporates a robust UL94V-0 rated nylon housing that ensures durability and resistance to environmental stresses. The shrouded structure protects the tin-plated brass contacts, while a positive locking latch mechanism guarantees secure mating and retention of the connector on the PCB.
With a rated current of up to 9.5A and a maximum voltage of 600V, this connector provides reliable electrical performance for high-power and signal applications. The male contacts, tin-plated for enhanced conductivity and corrosion resistance, are designed for solder termination, facilitating swift and strong connections during manufacturing.
The header's straight orientation and three-row configuration make it ideal for space-efficient layouts. The tail pin length of 3.69 mm supports effective soldering and retention. The connector is capable of operating within a wide thermal range, from -55°C to 105°C, making it suitable for devices exposed to varied environments.
The Mini-Universal MATE-N-LOK system is recognized for its robust locking capability and board locks, allowing secure mating and facilitating mechanical retention during production. For compatible mating connectors, refer to Mini-Universal MATE-N-LOK plug housings using socket contacts, ensuring complete system integration.
This PCB header is suited for industrial equipment, instrumentation, manufacturing controls, consumer electronics, and any application requiring dependable wire-to-board interfaces. Bulk packaging is available for efficiency in automated production lines.
Explore more PCB Headers and wire-to-board solutions from TE Connectivity in the Electronics & Electricals category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum current rating for this model is 9.5A.
This connector has a maximum operating voltage of 600V.
The pitch size of the contacts is 4.14 mm.
This model features 9 contacts arranged in 3 rows.
The tail pin length of the contacts is 3.69 mm.
The housing is constructed from UL94V-0 rated nylon.
This connector uses solder termination for mounting on printed circuit boards.
The operating temperature range is from -55°C to 105°C.
This model has a straight orientation.
This PCB header is shrouded, providing additional protection for the contacts.
This connector is suitable for industrial equipment, instrumentation, manufacturing controls, and consumer electronics requiring wire-to-board interfaces.
The country of origin for this model is India.
