RS PRO PCB Transformer 2 Output 5 to 24 V AC, Through Hole, 12 VA, Dual Secondary, 230 V AC Primary, 43×45×30.41 mm 504-515

Free Delivery in India | Lowest Global Shipping Charges

RS PRO PCB Transformer 2 Output 5 to 24 V AC, Through Hole, 12 VA, Dual Secondary, 230 V AC Primary, 43×45×30.41 mm 504-515

Name: RS PRO PCB Transformer 2 Output 5 to 24 V AC, Through Hole, 12 VA, Dual Secondary, 230 V AC Primary, 43×45×30.41 mm 504-515
Brand: RS PRO
SKU: 86256
Price: 38.58 USD
Availability: InStock



Category PCB Transformer Brand RS PRO Condition New

Specifications

Country of Origin	Poland
Brand	RS PRO
Length	43mm
Model	504-515
Depth	30.41mm
Gross Weight	400g
Width	45mm
Mount Type	Through Hole
Maximum Operating Temperature	130°C
Number of outputs	2
Winding Type	Dual Secondary
Primary Voltage	230 V ac
Secondary Voltage	5 to 24 V ac
Minimum Operating Frequency	50Hz
Maximum Operating Frequency	60Hz

Key Features

Provides 2 independent AC outputs ranging from 5 to 24 V for versatile circuit design.
Supports a primary voltage of 230 V AC for global compatibility.
Features dual secondary winding for flexible voltage configuration, series or parallel.
Rated at 12 VA for reliable power delivery in demanding environments.
Through-hole PCB mounting ensures secure placement and stability on boards.
High isolation voltage (4 kVrms) for safe operation and electrical separation.
Compact dimensions of 43mm length, 45mm width, and 30.41mm depth allow easy integration.
Supports operating frequencies of 50 - 60 Hz, ideal for standard AC supplies.

Product Description

RS PRO’s model 504-515 PCB transformer is a high-performance device engineered for reliable AC power transformation in electronic and industrial settings. Designed with dual secondary windings, it delivers two versatile outputs ranging from 5 to 24 V AC, making it suitable for supplying multiple circuits or custom power rails on printed circuit boards.

The transformer accepts a 230 V AC primary input, supporting international voltage norms, and enables flexible secondary arrangements by series or parallel connection. Its power rating of 12 VA allows stable operation for various PCB assemblies, while the through-hole design ensures secure soldering and robust fitment during manufacturing.

Featuring a compact form factor - 43 mm in length, 45 mm in width, and 30.41 mm in depth - it fits space-constrained boards and enclosures. With a high isolation voltage of 4 kVrms, the transformer assures safe separation between primary and secondary circuits, reducing risks of electrical faults.

The unit operates efficiently at standard frequencies (50 - 60 Hz) and is tested for maximum operating temperatures up to 130°C, making it suitable for demanding environments such as industrial control panels, instrumentation, and automation systems. Its fully shrouded, laminated construction and double-section metric bobbin ensure enhanced safety and electromagnetic compatibility.

Quality and safety are validated through compliance with IEC/BS/EN 61558-2-6, IEC/BS/EN 61558-1, AS/NZS 61558.1 standards, RoHS directives, and CE approvals. The transformer is electrically and flash tested, with pins designed for stable board mounting.

Industrial and electronics use cases include PCB-based power supplies, instrumentation equipment, signal conditioning systems, automation controllers, and laboratory devices requiring low-voltage AC conversion with isolation.

Choose RS PRO for European-manufactured PCB transformers, ensuring performance, safety, and standards compliance. Explore more PCB Transformers for high-quality solutions to electronic power needs.
