Block PCB Transformer FL 10/6, 6 V AC, 2 Output Pins, 115 V/230 V Primary, Dual Secondary, Low Profile, DIN EN 61558-2-4

Block FL 10/6 PCB Transformer is a high-quality, low-profile component engineered for reliable power conversion and electrical isolation in demanding electronic applications. Engineered with dual secondary windings, this transformer delivers a 6 V AC output optimized for circuit protection and signal processing. It operates with versatility, supporting both 115 V AC and 230 V AC primary voltages, enabling use in international or dual-voltage designs.

This transformer’s primary windings can be configured for series or parallel operation, accommodating varying supply requirements and facilitating integration where power flexibility is essential. The secondary windings also support series or parallel wiring, delivering scalable output based on application demand.

Constructed with vacuum epoxy resin moulding to meet the UL94-V0 fire safety rating, the device includes double-section glass fibre reinforced polyamide bobbins that provide superior insulation and structural stability. The low inter-winding capacitance and minimized radiated noise assure reliable and consistent operation across a wide range of electronic environments.

Its compact footprint - 68 mm length, 22.8 mm width, and 57 mm depth - and a gross weight of 980 g enable straightforward installation onto PCBs via pin mounts, which accommodate secure and vibration-resistant attachment. Extra fixing holes support enhanced mechanical robustness during assembly.

Block FL 10/6 meets rigorous international standards and approvals including DIN EN 61558-2-4, UL 94 V-0, C-UL-US, VDE 0570 Teil 2-6, IEC 61558-2-4, and ENEC, ensuring safety, reliability, and regulatory compliance. Maximum operating temperature is rated at 40°C, with operational frequencies spanning from 50 Hz to 60 Hz, making it suitable for both traditional and modern power supply designs.

This transformer is ideal for industrial electronics, instrumentation panels, control systems, automation circuits, and commercial PCB assemblies. Its robust isolation voltage of 5000 V provides reliable protection for sensitive circuits, and its dual secondary design benefits designers seeking redundant or scalable power outputs.

In summary, Block FL 10/6 PCB Transformer is a versatile and dependable solution for power conversion applications requiring certified safety, robust construction, international compatibility, and compact design. Explore more PCB Transformers and advanced electrical components within the Block brand and corresponding industrial categories at EnvMart.
