RS PRO 24 V AC PCB Transformer Through Hole, 2 Output, Dual Secondary Dual Primary, 2 x 115 V AC Primary, 82% 504-353

Free Delivery in India | Lowest Global Shipping Charges

RS PRO 24 V AC PCB Transformer Through Hole, 2 Output, Dual Secondary Dual Primary, 2 x 115 V AC Primary, 82% 504-353

Name: RS PRO 24 V AC PCB Transformer Through Hole, 2 Output, Dual Secondary Dual Primary, 2 x 115 V AC Primary, 82% 504-353
Brand: RS PRO
SKU: 86254
Price: 39.91 USD
Availability: InStock



Category PCB Transformer Brand RS PRO Condition New

Specifications

Country of Origin	Poland
Brand	RS PRO
Efficiency	82%
Length	43mm
Model	504-353
Depth	33mm
Gross Weight	400g
Width	36mm
Mount Type	Through Hole
Maximum Operating Temperature	130°C
Number of outputs	2
Winding Type	Dual Secondary, Dual Primary
Primary Voltage	2 x 115 V ac
Secondary Voltage	24 V ac
Minimum Operating Frequency	50Hz
Maximum Operating Frequency	60Hz
Walsall Transformers 12V ac 2 Output Through Hole PCB Transformer, 6VABrand	Walsall Transformers

Key Features

High-quality PCB transformer with dual secondary and dual primary winding.
Rated 24 V AC secondary output for versatile circuit design.
2 x 115 V AC primary voltage suited for international input compatibility.
Delivers two distinct output channels supporting multi-circuit applications.
Impressive 82% efficiency for reduced energy loss in operation.
Compact dimensions for space-constrained PCB layouts.
Through-hole mounting provides secure and durable installation.
4 kVrms isolation voltage enhances safety and electrical protection.

Product Description

RS PRO Model 504-353 PCB Transformer is a premium 24 V AC transformer designed specifically for printed circuit board (PCB) mounting. It features a dual secondary, dual primary winding arrangement, allowing for flexible connection options in series or parallel. The transformer delivers two output channels at 24 V AC, meeting requirements for multi-circuit and industrial control boards.

The primary voltage is rated at 2 x 115 V AC, making it suitable for a broad range of input sources. With a power capacity of 12 VA and a high efficiency rating of 82%, the transformer ensures reliable power delivery with minimal losses. Its through-hole mounting design incorporates robust pins for easy and secure installation on PCBs. The isolation voltage of 4 kVrms provides enhanced safety and electrical protection for sensitive electronics.

Designed for durability and space constraint optimization, the transformer measures 43 mm in length, 36 mm in width, and 33 mm in depth, and weighs 400 grams. It operates efficiently across a frequency range of 50 Hz to 60 Hz and withstands a maximum operating temperature of 130°C, making it ideal for both commercial and industrial environments such as control panels, embedded systems, medical equipment, and monitoring systems.

The transformer meets key standards/approvals including ASNZS 61558..6, RoHS, ASNZS 61558.1, CE, IECBSEN 615581, and IECBSEN 615586, and is manufactured in Poland. Its dual winding supports versatile PCB design, facilitating either a flexible output voltage or increased current handling. The product complies with ANSI/ESD S20.20:2014 and BS EN 61340-5-1:2007 for electrostatic control, ensuring safe integration into static-sensitive applications.

This transformer is particularly suited for applications requiring isolation and reliable low-voltage AC supply in industrial automation, instrumentation, and electronics manufacturing. With its compact size, robust build, and high-performance ratings, RS PRO 504-353 is a preferred choice for professional PCB assembly, laboratory instrumentation, and commercial electronics projects.

Explore more PCB Transformers and electronics solutions within the RS PRO category at EnvMart.
