Eaton xPole PXL Miniature Circuit Breaker, 3-Pole, 25A, Type D, 400V AC, 48V DC, 10kA, DIN Rail, IP20 236467 PXL-D25/3

Eaton's xPole PXL Miniature Circuit Breaker, model 236467 PXL-D25/3, is a robust electrical protection device designed for demanding industrial and commercial environments requiring high-performance circuit protection and reliability. This unit offers a 3-pole configuration, allowing simultaneous protection of three circuits or phases, and is rated for a current capacity of 25 amperes, making it ideal for a wide range of electrical distribution applications where precise overload and short-circuit protection is essential.

The circuit breaker features a Type D tripping characteristic, providing high selectivity and fast response to electrical faults. This classification is particularly suited for installations with high inrush currents, such as those commonly found in motor and transformer applications. It supports operational voltage up to 400V AC and 48V DC, enabling compatibility across diverse system requirements and power sources.

Installation is straightforward thanks to its DIN rail mount design and quick-fit action with three locking positions. The device incorporates double terminal lift/jaw connections at both the top and bottom, offering flexibility for rail arrangement and bus bar compatibility. Safety is paramount with its IP20-rated enclosure, providing protection against accidental contact and ingress of dust or small objects. The breaker is finger-proof and back-of-hand-proof, minimizing electrical hazards during handling and service.

Testing and conformity to global standards are assured, with the product certified under IEC/EN 60898 specifications. This ensures reliable performance and adherence to best practices for circuit breaker technology. The breaker mechanism is electromagnetic, which ensures rapid and reliable instantaneous break times in the event of overloads or short circuits. The toggle switch actuator allows for user-friendly reset and manual operation after a tripping event.

The compact dimensions of 80mm width, 52.5mm height, and 60mm depth enable easy integration into standard electrical panels with minimal space requirements. Its construction and features make it a robust choice for environments like manufacturing plants, commercial buildings, data centers, and other locations demanding secure circuit protection.

Common applications include power distribution, motor and lighting control, HVAC systems, and process automation. Its high breaking capacity of 10kA ensures protection even in high fault current scenarios. The xPole PXL Miniature Circuit Breaker is also designed for compatibility with accessories and integration with bus bar systems for expanded functionality.

Explore the full range of industrial and commercial circuit protection products from Eaton to find solutions tailored to your electrical safety and operational needs.
