ABB S800N Miniature Circuit Breaker High Performance, 3-Pole, 80A, Type D, 690V AC, 375V DC, 36kA Breaking 2CCG001244R0001

ABB 2CCG001244R0001 S800N Series Miniature Circuit Breaker stands out as a high performance MCB engineered for demanding electrical circuit protection. Designed with a three-pole configuration, it ensures comprehensive protection in commercial or residential electrical panels where high current loads and fault tolerance are critical. The breaker supports an 80A current rating, making it suitable for installations with substantial power demands.

This versatile MCB accommodates both 690V AC and 375V DC operating voltages, allowing flexible deployment across electrical systems. Its Type D tripping characteristics are tailored to applications with high inrush currents, such as motor loads or circuits with surge-prone devices. The device incorporates both electromagnetic and thermomagnetic tripping mechanisms to guard against overloads and short circuits reliably.

The S800N series breaker features a robust 36kA breaking capacity, ensuring that fault currents are contained safely, minimizing risk to property and personnel. Installation is streamlined by the DIN rail mounting format, with compact dimensions (80mm width, 95mm height, 88.5mm depth) that fit into limited panel spaces. The toggle switch actuator simplifies manual reset operations after tripping events, supporting ease of maintenance and operation.

A cage terminal design allows secure wire connections, complemented by the IP20 enclosure rating, which provides effective protection against accidental contact and ingress of solid objects. ABB's S800N range maintains compliance with standards IEC/EN 60947-2 and IEC/EN 60898-1, affirming suitability for industrial and commercial use.

Use cases include high-demand commercial electrical installations, residential panels for lighting and power circuits, and any application requiring a dependable, high-capacity miniature circuit breaker. The device's compact size makes it ideal for confined installation environments.

As part of ABB's high-performance S800N series, the MCB offers engineers and installers a reliable solution for circuit protection needs, delivering advanced features and compliance with stringent industry norms. Browse related ABB Miniature Circuit Breakers and electrical protection devices in the EnvMart circuit protection categories.
