Souriau Sunbank by Eaton MIL Spec Circular Connector, 10 Way, Straight, 7.5A, 500V, Male Plug, Copper Alloy 85106J1210S50
Specifications
| Country of Origin | France |
|---|---|
| Voltage | 500V |
| Brand | Souriau Sunbank by Eaton |
| Orientation | Straight |
| Current | 7.5A |
| Model | 85106J1210S50 |
| IP Rating | IP65 |
| Mount Type | Cable |
| Contact Material | Copper Alloy |
| Series | 851 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | FBI |
| Contact Plating | Gold |
| Number of Contacts | 10 |
| Contact Gender | Female |
| Connector Gender | Male |
| Shell Size | 12 |
| Military Standard | MIL-DTL-26482 |
| Mating Type | Bayonet |
| Shell Plating | Olive Drab Cadmium |
| Meets applicable national and international standards and specifications | NFC 93422 |
Key Features
- Provides ten gold-plated copper alloy contacts ensuring optimal electrical performance.
- Rated for 7.5A current and 500V working voltage, suitable for robust industrial and military applications.
- Features straight orientation and secure bayonet mating for quick, reliable connections.
- An IP65 ingress protection rating offers dust-tight and water jet resistance for harsh environments.
- Cable mount, olive drab cadmium plated shell is optimized for mechanical durability and corrosion resistance.
- Solder termination for 24 to 18 AWG wires supports strong, lasting wire-to-contact connections.
- Wide operating temperature range from -55°C to +125°C expands deployment capability.
- Conforms to MIL-DTL-26482 military specification and NFC 93422 standard for assured quality and performance.
Product Description
The Souriau Sunbank by Eaton 85106J1210S50 MIL Spec Circular Connector is expertly engineered for applications that demand robust, reliable, and versatile electrical connections. This straight male plug features a compact shell in size 12, fabricated from copper alloy and finished with an olive drab cadmium plating, combining mechanical resilience with corrosion resistance suited to defense, aerospace, railway, industrial automation, and instrumentation systems.
This connector’s ten gold-plated contacts ensure low resistance and superior conductivity, handling currents up to 7.5A at a working voltage of 500V. It is well-suited for secure transmission of power or signal in challenging field conditions, from control and measurement instruments to mobile military hardware. The secure bayonet mating interface allows for quick and error-free engagement and disengagement, while the straight cable output simplifies wiring in constrained or panel-mount situations.
Designed for solder termination, the connector supports wire sizes from 24 to 18 AWG (0.21 to 0.93 mm²), enabling robust and vibration-resistant connections. Rated to IP65, it withstands dust and powerful water jets, making it ideal for outdoor and harsh industrial environments. Its operating temperature range from -55°C to 125°C provides exceptional thermal stability for use in extreme climates.
Compliant with strict international standards such as MIL-DTL-26482 and NFC 93422, this connector is trusted for use in mission-critical systems. Its high contact density, durability, and backed-by-standard design make it a staple in equipment for aerospace, process automation, railway, defense electronics, and heavy machine tools.
For engineers needing a compact, rugged Circular Connector capable of high performance and reliability under demanding conditions, the 85106J1210S50 is a proven choice. Browse more Souriau Sunbank by Eaton connectors and circular interface solutions on EnvMart for comprehensive connectivity requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum current rating for this model is 7.5A.
This connector is rated for a working voltage of 500V.
It features ten gold-plated contacts for optimal electrical performance.
This model uses solder termination for wire sizes ranging from 24 to 18 AWG.
The connector has an IP65 ingress protection rating, making it dust-tight and resistant to water jets.
It operates within a temperature range of -55°C to +125°C.
The shell size of this model is size 12.
The connector is made from a copper alloy and features an olive drab cadmium plated shell for corrosion resistance.
It conforms to the MIL-DTL-26482 military specification.
This model features a bayonet mating interface for secure connections.
This connector is suitable for use in defense, aerospace, railway, industrial automation, and instrumentation systems.
The country of origin for this connector is France.
