Samtec HTST Series Straight Surface PCB Header, 10 Contacts, 2.54 mm Pitch, Shrouded, Surface Mount HTST-105-01-S-DV
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 1kV |
| Brand | Samtec |
| Orientation | Straight |
| Current | 3.4A |
| Model | HTST-105-01-S-DV |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | HTST |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 10 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- Features a 2.54 mm pitch for reliable PCB mounting.
- Includes 10 male contacts arranged in 2 rows for efficient connectivity.
- Shrouded design ensures secure mating and polarization.
- Constructed from liquid crystal polymer for durability and high temperature resistance.
- Phosphor bronze contacts plated with gold provide high conductivity and corrosion resistance.
- Supports current up to 3.4A and rated voltage of 1 kV.
- Operates in harsh environments from -55°C to 125°C.
- Surface mount termination for modern assembly processes.
Product Description
Samtec HTST-105-01-S-DV is a straight surface mount PCB header featuring 10 male contacts arranged in 2 rows with a 2.54 mm pitch, designed to facilitate reliable wire-to-board connections in industrial electronics.
This shrouded connector is constructed with a liquid crystal polymer housing, providing resistance to high temperatures and mechanical stress. The gold-plated phosphor bronze contacts ensure excellent electrical conductivity as well as protection against oxidation, making it ideal for demanding environments.
With a current rating of 3.4A and maximum voltage of 1 kV, the HTST-105-01-S-DV header is suitable for a variety of applications including laboratory equipment, manufacturing controls, instrumentation, and industrial automation. Operating temperatures range from -55°C to 125°C, allowing it to perform reliably even under extreme conditions.
The shrouded design includes a polarization notch for secure and error-free mating, reducing the risk of incorrect connections. The surface mount termination is compatible with contemporary PCB assembly processes, ensuring ease of integration and robust mechanical retention.
Wire-to-board connector systems such as this model are widely used in construction of electronics where signal integrity and modularity are critical. The HTST Series supports most common pin counts, with this model providing 10 contacts for medium-density signal or power distribution.
2.54 mm pitch for standard PCB layouts. 10 contacts, male, oriented straight in 2 rows. Shrouded, polarization notch for secure mating. Liquid crystal polymer housing resists heat and chemicals. Gold-plated phosphor bronze contacts for conductivity and durability.
3.4A current rating, 1 kV voltage rating. Wide operating temperature: -55°C to 125°C. Surface mount termination. Wire-to-board system for modular connection in electronics.
Industrial, laboratory, manufacturing, and electronics sectors benefit from the HTST-105-01-S-DV for applications including control boards, test equipment, and embedded system interfaces.
Browse more connector solutions in EnvMart’s PCB Header category or discover the full Samtec range for advanced electronic interconnects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this PCB header is 2.54 mm, designed for reliable PCB mounting.
This model features 10 male contacts arranged in 2 rows for efficient connectivity.
The maximum voltage rating for the HTST-105-01-S-DV is 1 kV.
This PCB header has a current rating of 3.4A.
The housing is made from liquid crystal polymer, and the contacts are phosphor bronze plated with gold for high conductivity and corrosion resistance.
It operates within a temperature range of -55°C to 125°C, making it suitable for harsh environments.
The HTST-105-01-S-DV uses surface mount termination, compatible with modern PCB assembly processes.
The shrouded design includes a polarization notch that ensures secure and error-free mating, reducing the risk of incorrect connections.
This model is suitable for applications including laboratory equipment, manufacturing controls, instrumentation, and industrial automation.
The contacts are oriented straight in 2 rows, facilitating efficient connectivity.
The HTST-105-01-S-DV supports a wire-to-board connector system, which is critical for modular connections in electronics.
The HTST-105-01-S-DV PCB header is manufactured in India.
