Hanna Blackstone 5 L/h Chemical Dosing Pump -BL5
Specifications
| Country of Origin | India |
|---|---|
| Package Contents | 5 x 8 mm polyethylene tubing, 1/4 inch injection fitting |
| Power Consumption | 200 W |
| Frequency | 50/60 Hz |
| Relative Humidity | Max 95% non-condensing |
| Brand | BlackStone |
| Power Supply | 110/115 VAC, 50/60Hz |
| Body Material | Fibre-reinforced polypropylene |
| Flow Rate | 5.0 LPH |
| Dimensions | 165 x 194 x 121 mm |
| Mounting | Horizontal/Vertical |
| Dimensions (LxWxH) | 165 x 194 x 121 mm |
| Operating Temperature Range | 0 to 50 °C |
| Model | BL5 |
| Tubing | Polyethylene 5 x 8 mm |
| IP Rating | IP65 |
| Weight | 3 KG |
| Protection Class | IP65 |
| Valve Type | Glass ball valves |
| Maximum Pressure | 7 bar |
| Diaphragm Material | PTFE (PolyTetraFluoro-Ethylene) |
| Fuse | 250V |
| Casing Material | Fibre-reinforced Polypropylene |
| Operating Voltage | 110/115 V AC |
| Product Condition | New |
| MPN | BL5 |
| Maximum Flow Rate | 5 LPH |
| Self Priming Height | 1.5 m |
| Valve Material | Glass ball valves |
| O-Ring Material | Viton® |
| Pumphead Material | PVDF (PolyVinyliDene Fluoride) |
| Injection Fitting | 1/4 inch |
| Dosing Frequency | 120 strokes per min |
| Self-priming Height | 1.5 m |
| Dosing Pumphead Material | PVDF (PolyVinyliDene Fluoride) |
| O-Rings Material | Viton® |
| Fuse Rating | 250 V |
| Relative Humidity (Non-Condensing) | Up to 95% |
Key Features
Hanna BL5 Chemical Dosing Pump delivers precise chemical dosing at up to 5 LPH and 7 bar pressure for demanding industrial processes.Maximum flow rate of 5 litres per hour ensures accurate chemical dosing.Operates under high pressures up to 7 bar for versatile process requirements.PTFE diaphragm and PVDF pumphead deliver superior chemical resistance and reliability.Rugged fibre-reinforced polypropylene body designed for industrial durability.Glass ball valves and Viton® O-rings provide consistent, leak-free performance.IP65-rated enclosure allows safe use in tough, dusty environments.Self-priming up to 1.5 meters for easy installation and startup.Flexible mounting, allowing both horizontal and vertical installation.Operates at 110/115V, 50/60Hz with 200W power consumption.Includes 5 x 8 mm polyethylene tubing and 1/4 inch injection fitting for easy integration.
Product Description
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum flow rate of the Hanna BL5 Chemical Dosing Pump is 5 litres per hour (LPH), ensuring accurate chemical dosing for your industrial applications.
The Hanna BL5 can handle pressures up to 7 bar, making it suitable for various demanding industrial processes.
The pump features a PTFE diaphragm and PVDF pumphead for chemical resistance, a fibre-reinforced polypropylene body for durability, and glass ball valves with Viton® O-rings for leak protection.
Yes, the pump has an IP65-rated enclosure, which protects it against dust and water ingress, making it suitable for harsh industrial settings.
The Hanna BL5 has a self-priming capability of up to 1.5 meters, facilitating easy installation and startup.
The Hanna BL5 operates on a power supply of 110/115 VAC at 50/60Hz, with a power consumption of approximately 200W.
Yes, the Hanna BL5 allows for flexible mounting options, supporting both horizontal and vertical installations to fit your space requirements.
The operational temperature range for the Hanna BL5 is from 0 to 50 °C, with a maximum relative humidity of 95% (non-condensing).
The Hanna BL5 comes with 5 x 8 mm polyethylene tubing and a 1/4 inch injection fitting for easy integration into your system.
Yes, the Hanna BL5 is specifically engineered for water treatment and wastewater management, providing precise and reliable chemical dosing.
