BlackStone BL20 Solenoid Chemical Dosing Pump 1.5 LPH, 13 Bar, IP65, PVDF | EnvMart

Free Delivery in India | Lowest Global Shipping Charges

Hanna Blackstone 18.3 L/h Chemical Dosing Pump - BL20

Name: Hanna Blackstone 18.3 L/h Chemical Dosing Pump - BL20
Brand: Hanna
SKU: 71439
Price: 263.83 USD
Availability: InStock



Category Dosing Pumps Brand Hanna Condition New

Specifications

Country of Origin	India
Power Consumption	200 W
Brand	BlackStone
Power Supply	110/115V, 50-60Hz
Body Material	Fibre-reinforced polypropylene
Dimensions	165 x 194 x 121 mm
Model	BL20
Tubing	Polyethylene 5 x 8 mm
IP Rating	IP65
Max. Pressure	13 bar
Weight	3 KG
Operating environment	0 to 50°C, RH max 95% non-condensing
Diaphragm Material	PTFE
Valves	Glass ball valves
Product Condition	New
MPN	BL20
Maximum Flow Rate	1.5 LPH
Self Priming Height	1.5 m
Pumphead Material	PVDF (PolyVinyliDene Fluoride)
Dosing Frequency	120 strokes/min
O-rings	FPM/FKM

Key Features

BlackStone BL20 solenoid driven chemical dosing pump offers robust performance for precise chemical metering in industrial and water treatment processes.

Solenoid driven positive displacement mechanism ensures consistent dosing accuracy.
Supports a maximum flow rate of 1.5 LPH and pressure up to 13 bar for demanding applications.
IP65 rated fibre-reinforced polypropylene casing guarantees durability in aggressive environments.
Pumphead made of PVDF and PTFE diaphragm for high chemical resistance and long service life.
Front-mounted valve assembly and controls enable easy installation and flow adjustments.
Flexible mounting options allow for horizontal or vertical placement on tank, wall, or floor.
Glass ball valves and FPM/FKM O-rings enhance operational reliability.
Operates within a temperature range of 0 to 50°C and a maximum 95% RH non-condensing.

Product Description

BlackStone BL20 solenoid driven chemical dosing pump is engineered for precise and reliable chemical dosing in industrial, laboratory, and water treatment applications. Featuring a maximum flow rate of 1.5 litres per hour and pressure capability up to 13 bar, the pump combines advanced solenoid technology with minimal moving parts, reducing wear and risk of mechanical failure compared to conventional motor-driven dosing pumps.

Solenoid driven positive displacement design ensures high repeatability and accuracy for process control.
1.5 LPH flow rate and up to 13 bar pressure handling meet most dosing requirements in chemical, water treatment, and laboratory sectors.
IP65 protected fibre-reinforced polypropylene casing is built for long-term industrial use in harsh environments.
PVDF pumphead and PTFE diaphragm materials offer excellent resistance to aggressive chemicals and corrosion.
Easy installation with a broad, flat base and versatile mounting holes for tank, shelf, wall, or floor placement.
Front-facing valve assembly and controls provide user-friendly operation and simple flow adjustment.
Glass ball valves and chemically resistant FPM/FKM O-rings ensure leak-proof dosing operations.
Operates at up to 120 strokes per minute with a maximum power consumption of 200 W at 110/115V, 50-60Hz.
Self-priming height up to 1.5 meters allows installation flexibility and operational confidence.

Typical industrial use cases include water treatment plants, chemical manufacturing, process industries, laboratories, and any application requiring exact metering of corrosive liquids. Package includes one BlackStone BL20 dosing pump, polyethylene tubing (5 x 8 mm), and all necessary valve fittings. The BL20 is part of BlackStone's high-performance pump series, designed for minimal maintenance and extended durability.

Explore more BlackStone dosing pumps and accessories in the Dosing Pumps category on EnvMart to meet diverse industrial chemical handling needs.

Hanna Blackstone 18.3 L/h Chemical Dosing Pump - BL20

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

Frequently Asked Questions

The BlackStone BL20 pump has a maximum flow rate of 1.5 litres per hour (LPH), making it suitable for various dosing applications.

The BL20 can handle pressures up to 13 bar, which is ideal for demanding industrial applications.

Yes, it features an IP65 rated fibre-reinforced polypropylene casing that ensures durability in aggressive environments.

The pumphead is made of PVDF and the diaphragm is PTFE, both of which offer high chemical resistance and longevity.

Yes, the pump features a broad, flat base with versatile mounting holes for easy installation on tanks, shelves, walls, or floors.

The BlackStone BL20 operates effectively within a temperature range of 0 to 50°C and a maximum relative humidity of 95% non-condensing.

The BL20 is designed for minimal maintenance, but regular checks for leaks and ensuring the diaphragm is in good condition are recommended.

The pump has a self-priming height of up to 1.5 meters, allowing for flexible installation options.

This pump is ideal for water treatment plants, chemical manufacturing, process industries, laboratories, and any application requiring precise metering of corrosive liquids.

The package includes one BlackStone BL20 dosing pump, polyethylene tubing (5 x 8 mm), and all necessary valve fittings for installation.
