Hanna Blackstone 1.5 L/h Chemical Dosing Pump - BL1.5

Free Delivery in India | Lowest Global Shipping Charges

Hanna Blackstone 1.5 L/h Chemical Dosing Pump - BL1.5

Name: Hanna Blackstone 1.5 L/h Chemical Dosing Pump - BL1.5
Brand: Hanna
SKU: 71442
Price: 263.83 USD
Availability: InStock



Category Dosing Pumps Brand Hanna Condition New

Specifications

Country of Origin	India
Power Consumption	200 W
Brand	BlackStone
Power Supply	110/115 VAC, 50/60Hz
Body Material	Fibre-reinforced polypropylene
Dimensions	165 x 194 x 121 mm
Environment	0 to 50°C, RH max 95% non-condensing
Model	BL1.5
Tubing	Polyethylene 5 x 8 mm
IP Rating	IP65
Weight	3 KG
Max Pressure	13 bar
Diaphragm Material	PTFE (Polytetrafluoroethylene)
Over Current Protection	250V fuse
Product Condition	New
MPN	BL1.5
Maximum Flow Rate	1.5 LPH
Self Priming Height	1.5 m
O-Ring Material	Viton®
Pumphead Material	PVDF (PolyVinyliDene Fluoride)
Injection Fitting	1/4 inch
Dosing Frequency	120 strokes/min
Valve Ball Material	Glass

Key Features

BlackStone BL1.5 Chemical Dosing Pump offers precision dosing at a maximum flow rate of 1.5 litres per hour and pressure up to 13 bar.

Designed for industrial chemical dosing applications.
Features a fibre-reinforced polypropylene casing and PVDF pump head for excellent chemical resistance.
Equipped with a PTFE diaphragm, Viton O-rings, and glass ball valves for durable operation.
Capable of both horizontal and vertical mounting, giving installation flexibility.
Delivers consistent and accurate dosing via a positive displacement mechanism.
Operates at a dosing frequency of 120 strokes per minute to maintain flow stability.
Maximum self-priming height is 1.5 meters for reliable start-up.
Environment rating: 0 to 50°C, RH up to 95%, and ingress protection IP65.
Power supply: 110/115V AC, 50/60Hz with over-current protection included.
Compact dimensions: 165 x 194 x 121 mm and weight of approximately 3 kg.

Product Description

Hanna BlackStone BL1.5 Chemical Dosing Pump is a high-performance and reliable solution engineered for precise chemical dosing across industrial, laboratory, water treatment, and manufacturing applications. Designed to deliver consistent and accurate performance, this pump offers a maximum flow rate of 1.5 litres per hour and operates efficiently at pressures up to 13 bar, making it suitable for handling a wide range of chemicals with varying viscosities. The pump is constructed with a robust fibre-reinforced polypropylene casing that ensures long-term durability, while the PVDF pump head provides excellent resistance against aggressive and corrosive chemicals. Its fixed PTFE diaphragm enhances operational life and ensures dependable dosing accuracy over extended periods, supported by Viton O-rings and glass ball valves that improve chemical compatibility and minimize wear.

Equipped with a positive displacement dosing mechanism, the pump guarantees repeatable and precise output with every stroke, while its dosing frequency of up to 120 strokes per minute enables fine-tuned process control for critical applications. The self-priming capability of up to 1.5 meters simplifies installation and startup, even in complex setups. Designed for versatility, the pump allows both horizontal and vertical mounting, with all controls and valves conveniently positioned on the front for easy access, adjustment, and maintenance. It operates efficiently in ambient temperatures ranging from 0 to 50°C with relative humidity up to 95%, ensuring stable performance in diverse working conditions.

For added protection and safety, the pump features an IP65-rated enclosure that safeguards against dust and water exposure, making it ideal for harsh industrial environments, along with built-in over-current protection through a 250V fuse. Its compact design, with dimensions of 165 x 194 x 121 mm and an approximate weight of 3 kg, allows seamless integration into existing systems without requiring significant space. This makes it a preferred choice for applications such as water and wastewater treatment, laboratory chemical dosing, agricultural use, process industries, and commercial chemical dispensing. Dosing Pumps
