Labtron LISA-A10 Image Particle Shape and Size Analyzer
Specifications
| Country of Origin | UK |
|---|---|
| Measuring range | 1 µm to 6000 µm |
| Output | USB 2.0 |
| Brand | Labtron |
| Light Source | 6 V / 20 W halogen lamp |
| Model | LISA-A10 |
| Technology | Computer image analysis technology |
| Digital camera | 3 million pixels |
| Type of Product | Particle Size Analyzer |
| Pixel Size | 3.2 µm × 3.2 µm |
| Stage Dimension | 185 × 140 mm |
| Particle Properties Measured | Morphology & size |
| Particle Shape Parameters | Aspect ratio / sphericity / surface ratio / specific surface area / circumscribed rectangle parameters etc. |
| Executive Standard | ISO13322-1 — 2004 |
| Static Collection | High-resolution JPG image of sample morphology |
| Single Particle Photo Data | Cross-sectional area / volume / aspect ratio etc. |
| Characteristic Parameters | D10 / D50 / D90 / D100 etc. |
| Objective Lens | 4X / 10X / 40X / 60X / 100X long distance achromatic (flat field) lens group |
| Eyepiece Lens | 1X / 10X / 16X wide field camera eyepiece lens |
| Maximum Amplification | 1600 |
| Stage Moving Range | 50 × 75 mm |
Key Features
- Well-designed professional optical microscope
- Latest high-speed CMOS camera
- Automatic analysis algorithm to improve accuracy rate of automated analysis
- Binarization methods to improve data processing and analysis capabilities
- Intuitive test results provide comprehensive understanding of morphology, status, process changes, and other product information
- Image stitching to produce seamless results and improve test representation and accuracy
- 12 automatic particle processing tool-set
- Intuitive measurement resolution up to 0.1 μm/pixel
- Provides clear image
- Wide measuring range
- User friendly
Product Description
Image Particle Shape and Size Analyzer LISA-A10 is an easy-to-operate and accurate particle characterization tool for measuring particle sizes in the range of over 1 μm to 6000 μm. It uses computer image analysis technology to analyze and process particle information obtained through a professional optical microscope and the latest high-speed CMOS camera. The system determines particle size distribution and particle morphology with precision and efficiency.
Applications:
Used in pharmaceutical research and quality control, food product particle sizing, chemical industry for granulation, milling, crystallization kinetics, and product formulation, abrasives, catalysts, ceramics, and related industries.
