Abracon 125MHz XO Crystal Oscillator ±30 ppm over -40°C to +85°C LVDS Surface Mount AK2DAF1-125.00000T

Free Delivery in India | Lowest Global Shipping Charges

Abracon 125MHz XO Crystal Oscillator ±30 ppm over -40°C to +85°C LVDS Surface Mount AK2DAF1-125.00000T

Name: Abracon 125MHz XO Crystal Oscillator ±30 ppm over -40°C to +85°C LVDS Surface Mount AK2DAF1-125.00000T
Brand: Abracon
SKU: 424174
Price: 5.27 USD
Availability: InStock



Category Crystal Oscillator Brand Abracon Condition New

Specifications

Country of Origin	India
Brand	Abracon
Height	1mm
Length	2.5mm
Model	AK2DAF1-125.00000T
Packaging	Tape & Reel
Width	2mm
Series	AK2
Maximum Operating Temperature	85°C
Output Frequency	125MHz
Package Type	Surface Mount
Minimum Operating Temperature	-40°C
Standards/Approvals	RoHS/RoHS II
Maximum Supply Voltage	3.63V
Minimum Supply Voltage	1.71V
Oscillator Type	XO
Output Level	LVDS

Key Features

Employs third overtone quartz crystal technology for high performance.
Delivers LVDS differential output level optimized for low power consumption.
Compact surface mount package measuring 2.5mm x 2mm x 1mm.
Operates within supply voltage range of 1.71V to 3.63V.
Complies with RoHS and RoHS II environmental standards.
Designed for industrial temperature range for reliability in harsh conditions.
Suitable for optical transceivers, networking and server systems applications.
Comes packaged in tape and reel format for automated PCB assembly.

Product Description

Abracon AK2DAF1-125.00000T is a high precision 125MHz XO Crystal Oscillator designed for demanding industrial and commercial electronic applications requiring frequency stability of ±30 ppm over a wide temperature range from -40°C to +85°C. This surface mount oscillator uses advanced 3rd overtone quartz crystal technology to deliver superior performance combined with very low rms jitter and minimal power consumption.

The oscillator features LVDS differential output for reliable signal integrity and operates within a low voltage supply range from 1.71V up to 3.63V, making it compatible with modern low-power electronic designs. Its miniature package measuring just 2.5mm in length, 2mm in width, and 1mm in height enables compact PCB layouts favored in optical transceivers, networking equipment, and server systems where space and performance are critical.

Designed to meet environmental regulations, the AK2DAF1-125.00000T complies with RoHS and RoHS II directives, ensuring it is free from hazardous substances. Packaged on tape and reel, it is optimized for automated surface mount assembly processes in manufacturing facilities.

Built on 3rd overtone quartz crystal technology to ensure excellent frequency stability and low jitter. Low power consumption with LVDS output level and multiple supply options. Compact surface mount package designed for space-constrained applications.

Wide temperature operating range from -40°C to +85°C suitable for industrial environments. Environmental compliant with RoHS and RoHS II standards. Tape and reel packaging supports high-volume automated assembly.

This crystal oscillator is ideal for industrial, networking, telecommunications, and server system designs requiring precise clocking solutions with dependable frequency accuracy across temperature variations.
