Microchip Operational Amplifier MCP6V99-E/ST 10 MHz Gain Bandwidth, 5-Pin SC-70-5, 5.5V

Microchip MCP6V99-E/ST operational amplifier offers a specialized solution for precision signal processing with a gain bandwidth product of 10 MHz. This model uses advanced CZero-Drift architecture to maintain an ultra-low input offset voltage of only 25 microvolts and an input offset current of 400 picoamperes. Housed in a compact 5-pin SC-70-5 surface mount package, it measures just 6.4 mm wide, 5.1 mm long, and 1.2 mm high, making it highly suitable for space-constrained circuit boards.

Powered by a stable 5.5V supply voltage, the device achieves a high slew rate of 9.5 V/µs, ensuring rapid signal changes without distortion. It provides an output current up to 30 mA, versatile for a broad range of low power applications in industrial and automotive electronics. The architecture also features enhanced electromagnetic interference (EMI) rejection to maintain signal integrity in noisy environments.

This operational amplifier is ideal for use in instrumentation, sensor interfaces, and precision amplification tasks requiring low noise and offset drift. The unity gain stability guarantees reliable operation in buffer and amplifier configurations. It does not conform to specific automotive standards but is suitable for general industrial environments.

Key features include a single channel design, 5-pin configuration, and surface mount compatibility to facilitate automated manufacturing processes. The MCP6V99 series continues Microchip's legacy of providing high precision operational amplifiers tailored for demanding electronics applications.

The amplifier features ultra-low input offset voltage of 25 microvolts for precise signal amplification. Input bias current is exceptionally low at 50 picoamperes, reducing error currents. It operates at a fixed supply voltage of 5.5V, ensuring consistent performance.

The device delivers a fast slew rate of 9.5V per microsecond, enabling quick response times. Max output current is 30 mA, suitable for various low power applications. The amplifier is unity gain stable and employs CZero-Drift architecture for minimal offset drift.

Compact dimensions of 6.4 mm width, 5.1 mm length, and 1.2 mm height optimize PCB space. Ideal for automotive and industrial systems with enhanced EMI rejection. The product comes in a surface mount SC-70-5 package suitable for modern electronics assembly.
