Microchip Operational Amplifier, 3 MHz Gain Bandwidth, 5-Pin SOT-23-5 Package MCP6476T-E/OT

Free Delivery in India | Lowest Global Shipping Charges

Microchip Operational Amplifier, 3 MHz Gain Bandwidth, 5-Pin SOT-23-5 Package MCP6476T-E/OT

Name: Microchip Operational Amplifier, 3 MHz Gain Bandwidth, 5-Pin SOT-23-5 Package MCP6476T-E/OT
Brand: Microchip
SKU: 423168
Price: 0.3 USD
Availability: InStock



Category Operational Amplifier Brand Microchip Condition New

Specifications

Country of Origin	India
Brand	Microchip
Height	1.45mm
Length	2.9mm
Model	MCP6476T-E/OT
Width	2.8mm
Mount Type	Surface
Series	MCP6476
Output Current	30mA
Maximum Operating Temperature	125°C
Package Type	SOT-23-5
Minimum Operating Temperature	-40°C
Number Of Channels	1
Standards/Approvals	RoHS
Pin Count	5
Automotive Standard	AEC-Q100
Maximum Supply Voltage	5.5V
GBP - Gain Bandwidth Product	3MHz
Input Bias Current	1 pA
Vos - Input Offset Voltage	1.6 mV
Slew Rate	3.2V/μs

Key Features

Operates at a single supply voltage of up to 5.5 V.
Low input offset voltage of ±1.6 mV enhances precision.
Rail-to-rail input and output capability ensures maximum dynamic range.
Unity gain stable ensuring stable operation in various configurations.
Enhanced EMI filtering reduces interference from external sources.
Wide operating temperature range from -40°C to +125°C.
Low quiescent current of 170 μA supports low-power applications.
Maximum output current of 30 mA allows driving moderate loads.

Product Description

Microchip MCP6476T-E/OT is a single-channel operational amplifier designed for precision analog signal amplification with a gain bandwidth product of 3 MHz.

This device features a low input offset voltage of ±1.6 mV, rail-to-rail input and output operation, and enhanced EMI filtering for optimal performance in noisy environments such as power lines, radio stations, and mobile communications.

The amplifier supports a wide supply voltage range from 1.8 V to a maximum of 5.5 V, drawing a low quiescent current of 170 μA, making it ideal for battery-powered and portable applications.

Its compact SOT-23-5 package with dimensions approximately 2.9 mm length, 2.8 mm width, and 1.45 mm height facilitates easy surface mounting on PCBs with space constraints.

Operating temperature ranges from -40°C to 125°C, and the part meets RoHS compliance and AEC-Q100 automotive standard, making it suitable for industrial, automotive, and consumer electronics applications.

Operates with supply voltages between 1.8 V and 5.5 V. Low input offset voltage and rail-to-rail input/output enable high accuracy. Enhanced EMI protection minimizes electromagnetic interference. Low power consumption supports portable and battery-powered devices.

Qualified to AEC-Q100 Grade 1 standards for automotive uses. Quick start-up time of 6 microseconds supports responsive applications. Compact 5-pin SOT-23 package suitable for space-constrained designs. Maximum output current of 30 mA allows driving capacitive and resistive loads.

Wide temperature range suitable for harsh environmental conditions. This versatile operational amplifier is applicable in various industrial, automotive, laboratory, communication, and consumer electronics sectors. Explore EnvMart's range of high-quality Operational Amplifiers for reliable and precision electronic system design.
