TE Connectivity 2 Axis Surface Accelerometer 3V to 5.5V 3 Wire TO-5 3-Pin 805M1-0020

TE Connectivity 805M1-0020 is a precision 2 Axis Surface Accelerometer designed for industrial and commercial applications requiring reliable vibration and motion sensing. Featuring an analogue voltage output and a 3 wire interface, this accelerometer operates on a supply voltage range of 3 V to 5.5 V, making it compatible with various sensor systems.

Housed in a compact TO-5 3-pin package suitable for surface mount, this accelerometer supports dynamic ranges from ±20g to ±500g, enabling it to measure a wide spectrum of acceleration forces accurately. The device boasts a flat frequency response up to 12 kHz, ensuring consistent sensor output across high-frequency vibrations.

Operating temperature range from -40°C to 100°C allows deployment in harsh industrial and automotive environments. With a sensitivity of 100 mV/g and a low supply current of 800 μA, the 805M1-0020 balances power efficiency with precise measurement capabilities. The device's dimensions (height 11.5 mm, length 8.89 mm) facilitate integration into equipment with limited space.

Equipped with NIST traceable amplitude calibration at 80 Hz, the accelerometer ensures compliance with strict calibration standards, boosting confidence in measurement accuracy. Its series TO-5 configuration provides reliable mechanical mounting and stable electrical connections.

Applications include vibration monitoring, industrial machinery diagnostics, automotive systems, and laboratory instrumentation where precise two-axis acceleration data is required. Manufactured to high-quality standards in China, the 805M1-0020 is suitable for a broad range of industrial, laboratory, and manufacturing use cases.

Measures acceleration across 2 axes for precise motion sensing. Suitable for surface mounting with TO-5 3-pin package. Flat frequency response up to 12 kHz ensures sensor fidelity. Operating temperature range from -40°C to 100°C supports harsh environments.

High sensitivity of 100 mV/g for accurate detection. Low supply current of 800 μA improves power efficiency. Compact size supports integration in small devices. NIST traceable amplitude calibration at 80 Hz assures measurement accuracy.

Robust TO-5 series design for stable mounting. Explore the TE Connectivity portfolio on EnvMart for comprehensive motion sensor ICs and accelerometers optimized for industrial and commercial applications.
