Microchip Operational Amplifier, SOT-23 5-Pin Surface Mount, 1.2 MHz Gain Bandwidth, 3.5V-16V Supply MCP6H01T-E/OT

Free Delivery in India | Lowest Global Shipping Charges

Microchip Operational Amplifier, SOT-23 5-Pin Surface Mount, 1.2 MHz Gain Bandwidth, 3.5V-16V Supply MCP6H01T-E/OT

Name: Microchip Operational Amplifier, SOT-23 5-Pin Surface Mount, 1.2 MHz Gain Bandwidth, 3.5V-16V Supply MCP6H01T-E/OT
Brand: Microchip
SKU: 420613
Price: 1.01 USD
Availability: InStock



Category Operational Amplifier Brand Microchip Condition New

Specifications

Country of Origin	India
Brand	Microchip
Height	1.3mm
Length	3.1mm
Model	MCP6H01T-E/OT
Width	1.8mm
Mount Type	Surface
Series	MCP6H01
Output Current	65mA
Maximum Operating Temperature	125°C
Package Type	SOT-23
Minimum Operating Temperature	-40°C
Number Of Channels	1
Quiescent Current	135 μA (typical)
Standards/Approvals	RoHS
Pin Count	5
Maximum Supply Voltage	16V
Minimum Supply Voltage	3.5V
GBP - Gain Bandwidth Product	1.2MHz
Input Bias Current	10 pA
Vos - Input Offset Voltage	±3.5 mV
Slew Rate	0.8V/μs
Input Offset Current	1 pA
Gain bandwidth product	1.2 MHz (typical)
Extended temperature range	-40°C to +125°C
Input offset voltage	±3.5 mV (max)
Single-Supply Operation	3.5V to 16V
Common Mode Rejection Ratio	100 dB (typical)
Dual-Supply Operation	±1.75V to ±8V

Key Features

Unity gain stable operational amplifier suitable for single-supply operation.
Wide operating voltage range from 3.5V up to 16V.
Low quiescent current consumption of 135 μA typical.
Input offset voltage maximum ±3.5 mV and low input bias current of 10 pA.
Rail-to-rail output for maximum output signal swing.
Operating temperature range from -40°C to +125°C for extended reliability.
Maximum output current of 65 mA for driving loads directly.
Compact SOT-23 surface mount package with 5 pins.

Product Description

The Microchip MCP6H01T-E/OT is a precision operational amplifier housed in a compact SOT-23 5-Pin surface mount package, designed for low power and high performance applications. It supports a wide single-supply voltage range from 3.5V to 16V, making it highly versatile for various electronic circuits.

This device features unity gain stability, enabling it to be used in voltage follower and buffer configurations with minimal effort. The low quiescent current of 135 μA per amplifier aids in low power consumption, beneficial for battery-powered and portable devices.

The operational amplifier provides rail-to-rail output capability, maximizing output voltage swing close to the supply rails. Input offset voltage is limited to ±3.5 mV maximum, with exceptionally low input bias and offset currents of 10 pA and 1 pA respectively, which enhance accuracy and reduce drift in sensor and instrumentation applications.

With a gain bandwidth product of 1.2 MHz and a slew rate of 0.8 V/μs, the MCP6H01 supports moderate-speed signal conditioning and amplification tasks. The device operates reliably over an extended temperature range from -40°C to +125°C, suitable for industrial and automotive electronics.

Unity gain stable operational amplifier for flexible usage. Wide supply voltage range from 3.5V to 16V supports single and dual supply operation. Low quiescent current ensures efficient power usage. Rail-to-rail output for maximum dynamic range.

Low input offset voltage and bias current for precision signals. Extended operating temperature range for harsh environments. Compact 5-pin SOT-23 surface mount package for space-saving designs.

This operational amplifier is ideal for use in electronics and electrical industries including signal conditioning, data acquisition, sensor interfaces, instrumentation, and general analog circuit design. The product complies with RoHS standards ensuring environmental safety.

Explore comprehensive solutions for your electronic component needs with Microchip Operational Amplifiers and related semiconductor products at EnvMart.
