RS PRO Push Button Switch Momentary Panel Mount SPST IP67 16 mm Cutout 36V DC 2A 175-9202

Name: RS PRO Push Button Switch Momentary Panel Mount SPST IP67 16 mm Cutout 36V DC 2A 175-9202
Brand: RS PRO
SKU: 420374
Price: 1929.68 INR
Availability: InStock



Category Push Button Switch Brand RS PRO Condition New

Specifications

Country of Origin	India
Brand	RS PRO
Model	175-9202
IP Rating	IP67
Mount Type	Panel
Series	RS PRO
Maximum Operating Temperature	70°C
Contact Configuration	SPST
Minimum Operating Temperature	-20°C
Panel Cutout Size	16 mm
Terminal type	Solder
Standards/Approvals	UL 94 V-0, UL 94 V-2
Switch Operation	Momentary
Contact DC Voltage	36V dc
Actuator Style	Flat
Switch Contact Current	2A

Key Features

The switch operates momentarily for quick on/off control.
It features a flat actuator style for ease of use.
Rated IP67 for water and dust resistance, suitable for harsh environments.
Supports contact DC voltage up to 36 V and current rating of 2A.
Operates within temperature range of -20°C to 70°C, ensuring reliability.
Compatible with solder terminal connections for secure mounting.
Constructed to meet UL 94 V-0 and UL 94 V-2 standards for safety and flame retardance.
Ideal for industrial control instruments, medical equipment, and security monitoring applications.

Product Description

RS PRO 175-9202 is a momentary push button switch designed for panel mounting applications requiring robust and reliable switching performance. This switch features a 16 mm cutout size and a single pole single throw (SPST) contact configuration, making it ideal for quick on/off control in electrical circuits. The flat actuator style offers a low-profile and user-friendly interface.

Constructed to meet IP67 ingress protection, the switch is both dust-tight and waterproof, enabling use in demanding industrial environments with exposure to contaminants. It supports a maximum contact DC voltage of 36 V and a contact current rating of 2A, suitable for low power control circuits. The solder terminal type ensures reliable electrical connections.

Designed with industrial durability in mind, the switch conforms to UL 94 V-0 and V-2 flame retardant standards, offering enhanced safety in operation. It is rated for operation in temperature ranges from -20°C up to 70°C, providing stable performance under various environmental conditions.

RS PRO push button switches from the MPB series deliver vandal resistance and long service life, making them suitable for applications such as industrial control instruments, medical equipment, security systems, vehicle peripherals, audiovisual equipment, and energy storage units. Their corrosion resistance, aesthetic design, and heat dissipation properties further enhance their suitability for harsh and public environments.

The switch operates momentarily for instantaneous control. Flat actuator design offers ergonomic user interface. High ingress protection to IP67 ensures dust and water resistance. Electrical rating of 36 V DC and 2A contact current.

Wide operating temperature range enhances versatility. Solder terminals provide secure connectivity. Compliance with UL 94 V-0 and V-2 standards for safety. Suitable for diverse industrial and medical applications. Explore the comprehensive range of RS PRO Push Button Switches and components at EnvMart for industrial, automation, and control needs.
