Gefran Panel DIN Rail Power Controller Solid State Relay 3 Phase 760V 250A GTF-25-480-0-0-0-0 1-B-M
Specifications
| Country of Origin | Italy |
|---|---|
| Display Type | LED |
| Brand | Gefran |
| Length | 60mm |
| Model | GTF-25-480-0-0-0-0 1-B-M |
| Width | 143mm |
| Mount Type | Panel, DIN Rail |
| Output type | Solid State Relay |
| Series | GTF |
| Input Type | Analogue |
| Maximum Operating Temperature | 50°C |
| Control Type | 3 Phase |
| Minimum Operating Temperature | 0°C |
| Interfaces | USB - TTL cable) |
| Maximum Current | 250A |
| Standards/Approvals | CE, UL, TÜV, UL508, CSA, EN 60947-4-3 |
| Maximum Supply Voltage | 760V |
| Digital Comms | Modbus RTU, RS485 |
| Panel Depth | 170.4mm |
Key Features
- The device supports analog input types configurable in volts, mA, or potentiometer signals.
- It offers multiple trigger modes including zero crossing, fixed cycle, burst firing, and phase angle control.
- Communication interfaces include Modbus RTU over RS485 and USB TTL cable for configuration.
- Incorporates optional resettable electronic fuses and load interrupt alarms for enhanced safety.
- Designed for operating temperatures between 0°C and 50°C with LED display for status indication.
- Complies with CE, UL, TÜV, UL508, CSA, and EN 60947-4-3 standards.
- Suitable for monophase and triphase applications with configurable current limits and feedback options.
- The unit dimensions are 60mm length, 143mm width, and 170.4mm panel depth.
Product Description
Gefran GTF-25-480-0-0-0-0 1-B-M Power Controller is a high-performance 3 Phase Solid State Relay designed for panel and DIN Rail mounting. Rated for a maximum current of 250A and a maximum supply voltage of 760V, this device is ideal for industrial, automation, and process control applications requiring reliable power management.
The controller supports an analogue input interface configurable for volt, milliamp, or digital potentiometer signals via PWM. It features multiple trigger modes, including zero crossing, fixed cycle, burst firing, and phase angle control to adapt to various load types and control requirements.
Advanced features include optional resettable electronic fuses for overload protection, total and partial load interrupt alarms, and configurable current limits. Communication capabilities are enhanced with Modbus RTU over RS485 and USB TTL cable connectivity for easy configuration and integration into automation systems.
With LED status display and a wide operating temperature range from 0°C to 50°C, this power controller meets multiple international certifications including CE, UL, TÜV, UL508, CSA, and EN 60947-4-3. Its compact dimensions of 60mm length, 143mm width, and 170.4mm panel depth ensure easy installation in electrical panels.
Manufactured in Italy, the product is designed for monophase and triphase applications, providing robust control for industrial power systems. The GTF series blends safety, precision, and flexibility making it well-suited for automation, manufacturing, HVAC, and other industrial sectors.
The device supports analog input types configurable in volts, mA, or potentiometer signals. It offers multiple trigger modes including zero crossing, fixed cycle, burst firing, and phase angle control. Communication interfaces include Modbus RTU over RS485 and USB TTL cable for configuration.
Incorporates optional resettable electronic fuses and load interrupt alarms for enhanced safety. Designed for operating temperatures between 0°C and 50°C with LED display for status indication. Complies with CE, UL, TÜV, UL508, CSA, and EN 60947-4-3 standards.
Suitable for monophase and triphase applications with configurable current limits and feedback options. The unit dimensions are 60mm length, 143mm width, and 170.4mm panel depth. Manufactured in Italy, ensuring high quality and reliability.
Explore our extensive range of industrial Power Controllers and automation solutions at EnvMart for reliable performance and certified quality.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum current rating of this solid state relay is 250A.
The maximum supply voltage for this power controller is 760V.
The dimensions of this model are 60mm in length, 143mm in width, and 170.4mm in panel depth.
It supports analog input types configurable in volts, milliamps, or potentiometer signals.
The device features communication interfaces including Modbus RTU over RS485 and a USB TTL cable for configuration.
It offers multiple trigger modes, including zero crossing, fixed cycle, burst firing, and phase angle control.
The operating temperature range for this unit is between 0°C and 50°C.
This product complies with CE, UL, TÜV, UL508, CSA, and EN 60947-4-3 standards.
This power controller is designed for panel and DIN Rail mounting.
Yes, it incorporates optional resettable electronic fuses and load interrupt alarms for enhanced safety.
It features an LED display for status indication.
Yes, it is suitable for both monophase and triphase applications with configurable current limits.
