Microchip Operational Amplifier 10 MHz 8-Pin MSOP 3-6V Dual Channel MCP6292-E/MS
Specifications
| Country of Origin | India |
|---|---|
| Brand | Microchip |
| Height | 0.85mm |
| Length | 3mm |
| Model | MCP6292-E/MS |
| Width | 3mm |
| Mount Type | Surface |
| Series | MCP6292 |
| Output Current | 25mA |
| Maximum Operating Temperature | 125°C |
| Package Type | MSOP |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 2 |
| Standards/Approvals | RoHS |
| Pin Count | 8 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 6V |
| Minimum Supply Voltage | 3V |
| GBP - Gain Bandwidth Product | 10MHz |
| Input Bias Current | 1 pA |
| Vos - Input Offset Voltage | 5 mV |
| Slew Rate | 7V/μs |
Key Features
- Dual channel operational amplifier in a compact MSOP package.
- Gain bandwidth product of 10 MHz ensuring fast response.
- Operates reliably with supply voltages from 3V to 6V.
- Low input bias and offset currents for precision applications.
- Output current capable of up to 25 mA suitable for various electronics applications.
- Wide operating temperature range from -40°C to 125°C for harsh environments.
- Designed according to AEC-Q100 automotive standards ensuring high reliability.
- RoHS compliant for environmental safety.
Product Description
Microchip MCP6292-E/MS is a precision dual operational amplifier featuring a gain bandwidth of 10 MHz and packaged in an 8-pin MSOP surface-mount package. It is designed to operate with a minimum supply voltage of 3V and a maximum up to 6V, providing flexibility for a variety of low-voltage applications.
This operational amplifier offers low input bias current of 1 picoampere and a low input offset voltage of 5 millivolts, making it highly suitable for high-accuracy signal processing and amplification tasks.
Its fast slew rate of 7 V/μs ensures rapid response to input signal changes, supporting high-speed signal conditioning needs. The device can deliver output current up to 25 mA, allowing for driving various loads in industrial, automotive, and consumer electronic circuits.
The small and compact footprint, with dimensions measuring only 3 mm by 3 mm by 0.85 mm, enables space-efficient designs on printed circuit boards where layout density is crucial.
Rated for a broad operating temperature range from -40°C up to 125°C, this amplifier is compliant with AEC-Q100 automotive standards, ensuring robust performance in automotive and other demanding applications. The device is also RoHS certified, meeting environmental standards for hazardous substances.
Dual channel operational amplifier with 10 MHz gain bandwidth. Compact 8-pin MSOP surface-mount package. Wide supply voltage range of 3 to 6 volts. Extremely low input bias and offset currents. Fast slew rate supporting high-speed operation.
High output current capability of 25 mA. Wide operating temperature range suitable for automotive use. Compliant with RoHS and AEC-Q100 standards. Ideal for industrial, automotive, laboratory, and electronics manufacturing.
Designed for efficient PCB integration with small dimensions.
This Microchip MCP6292-E/MS operational amplifier is suitable for use in industrial electronics, automotive systems, laboratory instrumentation, and various manufacturing applications. Its robust specifications ensure accurate amplification and signal conditioning in compact and cost-effective designs. For users looking for dependable operational amplifiers with high bandwidth and automotive-grade reliability, the MCP6292-E/MS offers an excellent solution.
Explore more high-quality Operational Amplifiers and semiconductor components at EnvMart to enhance your electronics projects and designs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The MCP6292-E/MS has a gain bandwidth product of 10 MHz, ensuring fast response for signal processing applications.
This model can deliver an output current of up to 25 mA, making it suitable for driving various loads in electronic circuits.
It operates with a supply voltage ranging from 3V to 6V, providing flexibility for low-voltage applications.
The operational amplifier has dimensions of 3 mm in length, 3 mm in width, and 0.85 mm in height, allowing for compact PCB designs.
It is rated for a wide operating temperature range from -40°C to 125°C, suitable for harsh environments and automotive applications.
The input bias current is extremely low at 1 picoampere, which is beneficial for precision applications.
The input offset voltage is specified at 5 millivolts, contributing to its suitability for high-accuracy signal processing.
The slew rate is 7 V/μs, allowing for rapid response to changes in input signals, supporting high-speed applications.
Yes, it is compliant with AEC-Q100 automotive standards and is also RoHS certified for environmental safety.
This operational amplifier is designed for surface mounting, specifically in an 8-pin MSOP package.
This model features dual channels, allowing for versatile applications in signal amplification.
It is suitable for use in industrial electronics, automotive systems, laboratory instrumentation, and various manufacturing applications.
