Hongfa Europe GMBH PCB Power Relay 24V DC Coil, 10A Switching Current, DPDT HF140FF/024-2ZTF
Specifications
| Country of Origin | China |
|---|---|
| Brand | Hongfa Europe GMBH |
| Height | 26.3mm |
| Length | 29mm |
| Model | HF140FF/024-2ZTF |
| Width | 13mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | HF140FF |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 10A |
| Terminal type | PCB Pin |
| Contact Resistance | 50mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 1.1kΩ |
| Coil Voltage | 24V dc |
| Switching DC Voltage | 30V dc |
| Switching AC Voltage | 250V |
| Coil Power | 530mW |
Key Features
- This relay is designed for PCB mounting with PCB pin terminals.
- It operates reliably in temperature ranges from -40°C to 85°C.
- The relay supports switching powers up to 2.5 kVA at 250V AC and 30V DC switching voltages.
- Coil resistance is 1.1 kΩ with coil power consumption of 530mW.
- It has silver alloy contacts for high durability and low contact resistance of 50mΩ.
- The relay withstands isolation voltage of 5 kVAC between coil and contacts.
- This RoHS-compliant relay is rated for up to 10 million operation cycles.
- Its compact dimensions are 29mm length, 13mm width, and 26.3mm height.
Product Description
Hongfa Europe GMBH HF140FF/024-2ZTF PCB Power Relay is a high-performance dual-pole double-throw (DPDT) relay designed specifically for printed circuit board mounting applications requiring reliable control switching. It features a coil voltage of 24V DC and supports switching currents up to 10A, making it suitable for intermediate power control tasks in various industrial and automotive applications.
This relay provides a switching power rating of up to 2.5 kVA at 250V AC and 30V DC, with durable silver alloy contacts that enhance conductivity and longevity. The coil resistance of 1.1 kΩ and coil power consumption of 530mW ensures efficient operation.
Engineered to operate in wide temperature ranges from -40°C to 85°C, the relay offers robust performance in harsh environments. It offers 5 kVAC isolation voltage between coil and contacts, ensuring electrical safety and noise immunity in control circuits.
The compact dimensions of 29mm length, 13mm width, and 26.3mm height allow for installation in space-constrained designs. The relay’s flux-proofed construction and RoHS certification confirm its environmental compliance and resistance to contaminants.
Suitable for industrial control systems, automotive electronics, HVAC equipment, manufacturing machinery, and automation projects, this relay provides reliable switching performance up to 10 million electrical cycles.
Designed for PCB mounting with PCB pin terminals for secure installation. Dual-pole double-throw (DPDT) contact configuration for versatile switching. Coil operates at 24V DC with 1.1 kΩ resistance. Switching current rating up to 10A at 250V AC and 30V DC switching voltages.
Silver alloy contacts ensure low resistance and high durability. Wide operating temperature range from -40°C to 85°C. Isolation voltage of 5 kVAC between coil and contacts. Flux-proofed and RoHS-certified construction for reliability and environmental compliance.
Compact dimensions support integration in limited spaces. Durable for up to 10 million switching cycles. Explore EnvMart catalogs for more Power Relays and electronic components to support your industrial and automation projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This relay has a switching current rating of up to 10A.
The coil voltage for this model is 24V DC.
The dimensions of this relay are 29mm in length, 13mm in width, and 26.3mm in height.
The maximum operating temperature for this model is 85°C.
It features a dual-pole double-throw (DPDT) contact configuration.
This relay has an isolation voltage of 5 kVAC between the coil and contacts.
The contacts are made of silver alloy, ensuring low contact resistance and high durability.
The coil resistance is 1.1 kΩ.
The coil power consumption is 530mW.
Yes, this relay is RoHS compliant, confirming its environmental compliance.
It supports switching voltages of up to 250V AC and 30V DC.
This model is rated for up to 10 million operation cycles.
