Hongfa Europe GMBH PCB Power Relay 5V DC Coil 10A Switching Current SPDT HF14FF/005-1ZSTF
Specifications
| Country of Origin | China |
|---|---|
| Brand | Hongfa Europe GMBH |
| Height | 26mm |
| Length | 29mm |
| Model | HF14FF/005-1ZSTF |
| Width | 13mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | HF14FF |
| Maximum Operating Temperature | 70°C |
| Contact Configuration | SPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 10A |
| Terminal type | PCB Pin |
| Contact Resistance | 50mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 47Ω |
| Coil Voltage | 5V dc |
| Switching DC Voltage | 30V dc |
| Switching AC Voltage | 277V |
| Coil Power | 530mW |
| Outline Dimensions | (29.0 x 13.0 x 26.0) mm |
Key Features
- Equipped with a 5V DC coil voltage for reliable operation.
- Single Pole Double Throw (SPDT) contact configuration enhances circuit flexibility.
- Capable of switching currents up to 10A for robust performance.
- PCB mount type with PCB pin terminals for easy installation.
- Operating temperatures ranging from -40°C to 70°C for diverse environmental adaptability.
- Contact material made from silver alloy ensuring excellent conductivity.
- Coil resistance measured at 47Ω with a coil power of 530mW for efficient power consumption.
- Physical dimensions of 29mm length, 13mm width, and 26mm height fit compact PCB layouts.
Product Description
Hongfa Europe GMBH HF14FF/005-1ZSTF is a high-quality PCB Power Relay designed with a 5V DC coil and a 10A switching current capacity. It features a Single Pole Double Throw (SPDT) contact configuration, making it highly versatile for controlling electrical circuits in industrial, automation, and electrical systems.
The relay is engineered for PCB mounting with PCB pin terminals, ensuring compact and secure installation on printed circuit boards. Its coil resistance of 47 ohms and coil power of 530mW contribute to its efficient electrical performance.
Operating reliably across a temperature range from -40°C to a maximum of 70°C, this relay suits various demanding environments. The contact material is silver alloy which provides excellent conductivity and durability, supporting switching AC voltages up to 277V and DC voltages up to 30V.
With outline dimensions of 29.0 x 13.0 x 26.0 mm, this relay is designed to save PCB space while delivering a switching power rating of 2.8 kVA. It also features a low contact resistance of 50mΩ, ensuring minimal voltage drop and power loss during operation.
Environmental compliance is ensured through RoHS certification, affirming the product’s adherence to hazardous material restrictions. The relay is sourced from China and intended for use in electrical, automation, manufacturing, and control system applications requiring reliable power relay switching.
5V DC coil voltage for stable relay operation. 10A switching current to handle moderate power loads. SPDT contact configuration for flexible circuit control. PCB mount with pin terminals for secure installation. Robust operation in temperatures from -40°C to 70°C.
Silver alloy contacts for high conductivity and longevity. Compact dimensions optimized for PCB space savings. 2.8 kVA switching power rating for demanding electrical loads. Low contact resistance minimizes energy loss and heat generation.
RoHS compliant ensuring environmental safety and regulations compliance.
This Hongfa Europe GMBH PCB Power Relay HF14FF/005-1ZSTF is ideal for use in industrial control systems, automation equipment, power supplies, and other electronic devices requiring precise and reliable power relay switching. For additional components and compatible parts, explore the full range of Power Relays and accessories at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model can handle a switching current of up to 10A, making it suitable for moderate power loads.
It operates with a coil voltage of 5V DC, ensuring reliable performance in various applications.
The relay features a Single Pole Double Throw (SPDT) contact configuration, allowing for flexible circuit control.
The outline dimensions of this relay are 29mm in length, 13mm in width, and 26mm in height.
It can operate reliably in temperatures ranging from -40°C to 70°C, suitable for diverse environmental conditions.
This model is designed for PCB mounting and features PCB pin terminals for secure installation.
The contacts are made from silver alloy, which ensures excellent conductivity and durability.
The coil resistance is measured at 47Ω, contributing to its efficient electrical performance.
It supports switching AC voltages up to 277V and DC voltages up to 30V.
The contact resistance is low at 50mΩ, minimizing voltage drop and energy loss during operation.
Yes, it is RoHS certified, ensuring compliance with hazardous material restrictions.
This relay is ideal for use in industrial control systems, automation equipment, and power supplies requiring reliable switching.
