Cosel DC/DC Converter 5V DC 1.2A 76V DC Input 18V Input 6W PCB Mount 7-Pin SIP-8 MGFS64805

Cosel MGFS64805 DC/DC Converter is a high-performance power supply module designed for industrial and electronic applications requiring reliable voltage conversion. With a regulated 5V DC output at 1.2A, it efficiently converts DC voltages ranging from 18V to 76V, suitable for diverse power conditions.

Designed for PCB mounting with a compact SIP-8 7-pin package, this converter ensures minimal circuit space usage while delivering up to 6W output power. The device boasts an isolation voltage of 1kV DC, providing electrical safety and noise immunity critical in industrial and manufacturing environments.

Performance highlights include a low ripple and noise level of 120mV peak-to-peak, enhancing the stability of sensitive electronic circuits. With an efficiency of approximately 84%, it offers energy savings and reduced heat dissipation. Operating temperatures up to 85°C allow it to function reliably in demanding HVAC, control systems, and instrumentation applications.

Integrated features such as overcurrent protection and remote ON/OFF functionality enable advanced power management and system control. This converter complies with key international safety and environmental standards including cUL, EN 62368-1, RoHS, and UL 60950-1, reflecting its suitability for wide industrial use.

The unit’s compact dimensions of 22mm length, 9.5mm width, and 12mm depth combined with its lightweight 7g design facilitate easy integration into tight PCB layouts. Manufactured in Japan, it guarantees quality and consistency for critical infrastructure projects.

Applications include industrial automation, power management in telecommunication equipment, embedded computer systems, laboratory instruments, and commercial electronics requiring stable DC power conversion.

This DC/DC converter features an output voltage of 5V DC with a maximum current of 1.2A. It supports a maximum input voltage of 76V DC and a minimum input voltage of 18V DC. The device is designed for PCB mount applications with a 7-pin SIP-8 package type.

Ripple and noise levels are at 120mV peak-to-peak, ensuring stable output power. It includes isolation voltage of 1kV DC for enhanced safety and reliability. The converter operates efficiently up to 84% and supports a maximum output power of 6W.

The operating temperature range extends up to 85°C, suitable for demanding industrial environments. Its compact dimensions are 22mm length, 9.5mm width, and 12mm depth with a weight of 7g. Equipped with integrated overcurrent protection and remote ON/OFF control for power management.

Manufactured in Japan to high industrial standards including cUL, EN 62368-1, RoHS, and UL 60950-1. Explore the broad range of Cosel products and DC/DC Converters at EnvMart to find the ideal power solution for your electronics and industrial needs.
