Cosel DC/DC Converter 15 V dc, -15 V dc, 100 mA Output, 5 V dc Input, 4.5 V Min Input, 3 W Power, SIP-6 Package MGW30515
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | Converters / DC-DC Converters Cosel MGW DC/DC Converter, 15V dc, -15 V dc/ 100 m |
| Brand | Cosel |
| Efficiency | 82% |
| Length | 17mm |
| Model | MGW30515 |
| Depth | 12mm |
| Gross Weight | 4g |
| Width | 8.5mm |
| Mount Type | PCB |
| Series | MGW |
| Maximum Operating Temperature | 85°C |
| Package Type | SIP-6 |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 2 |
| Ripple and Noise | 200mV Pk-Pk |
| Maximum Output Power | 3W |
| Maximum Input Voltage | 5V dc |
| Minimum Input Voltage | 4.5V |
| Number of Pins | 5 |
| Output Voltage 1 | 15, -15V dc |
| Output Current 1 | 100mA |
| Output Voltage Adjustment Range | 14.55 to 15.45 V |
| Isolation Voltage | 1kV dc |
| Output Current 2 | 0.1A |
Key Features
- Input voltage range from 4.5 V dc minimum to 5 V dc maximum ensures stable operation.
- Compact SIP-6 package designed for PCB mounting suitable for space-constrained environments.
- High isolation voltage of 1 kV dc ensures safety and reduces interference.
- Operating temperature range from -40 °C to 85 °C enables use in harsh environments.
- Ripple and noise level maintained at 200 mV peak-to-peak for clean output.
- Integrated overcurrent protection enhances device reliability and safety.
- Efficiency of 82% optimizes power conversion and reduces thermal stress.
- 5-pin single in-line package facilitates straightforward installation on printed circuit boards.
Product Description
Cosel MGW30515 DC/DC Converter offers dual voltage outputs of +15 V dc and -15 V dc with a nominal output current of 100 mA and a maximum output power of 3 W. Its precise voltage regulation with adjustment range from 14.55 to 15.45 V makes it ideal for sensitive electronic circuitry requiring stable power sources.
This converter operates from a low input voltage starting at 4.5 V dc up to a maximum of 5 V dc, making it suited for battery-powered and low-voltage applications. The device is packaged in a compact SIP-6 form factor designed for printed circuit board mounting, optimizing space use in electronic assemblies.
Featuring an isolation voltage rating of 1 kV dc and a ripple and noise specification of 200 mV peak-to-peak, this model ensures clean and reliable voltage outputs essential in communication, measurement, and control systems.
Operating reliably from -40 °C up to 85 °C, the MGW30515 is suitable for use in demanding industrial, laboratory, and commercial electronic environments. Its efficiency of 82% helps reduce energy loss and heat generation, facilitating longer operational life and safer performance.
The integrated overcurrent protection feature safeguards the converter and the connected electronics against potential damage due to excessive load conditions. Input voltage range from 4.5 V dc to 5 V dc. Output voltages of 15 V dc and -15 V dc with 100 mA current capacity.
3 W maximum output power rating for versatile applications. Compact SIP-6 package with 5 pins for easy PCB mounting. High isolation voltage of 1 kV dc for safety and noise reduction. Operating temperature from -40 °C to +85 °C suitable for harsh environments.
Ripple and noise level of 200 mV peak-to-peak for stable output. Efficiency of 82% optimizes power consumption and heat management. Standards compliance with UL62368-1, EN62368-1, RoHS, CSA, UKCA, and CE ensures quality and regulatory conformance.
This Cosel DC/DC converter series MGW is engineered for use in electronic components manufacturing, power supplies, telecommunications, instrumentation, and embedded systems requiring reliable dual output voltage sources. Its PCB mounting capability supports compact, space-saving designs.
Explore our extensive range of DC/DC Converters and other electronics at EnvMart, your trusted source for advanced power management components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model provides dual output voltages of +15 V dc and -15 V dc with a nominal output current of 100 mA.
The input voltage range for the MGW30515 is from 4.5 V dc to 5 V dc.
The maximum output power rating of this unit is 3 W.
This model has an efficiency rating of 82%, optimizing power conversion and reducing thermal stress.
The SIP-6 package has dimensions of 17 mm in length, 12 mm in depth, and 8.5 mm in width.
The operating temperature range for the MGW30515 is from -40 °C to +85 °C.
The ripple and noise level is maintained at 200 mV peak-to-peak for clean output.
This converter is designed for PCB mounting, making it suitable for space-constrained environments.
The MGW30515 includes integrated overcurrent protection and has an isolation voltage rating of 1 kV dc to ensure safety and reduce interference.
This model complies with UL62368-1, EN62368-1, RoHS, CSA, UKCA, and CE standards.
The MGW30515 has two outputs: +15 V dc and -15 V dc.
The output voltage adjustment range is from 14.55 V to 15.45 V.
