Bourns Shielded Multilayer Surface Mount Inductor with Carbonyl Powder Core 10 μH 20% Tolerance 1.8 A Idc SRP4020TA
Specifications
| Country of Origin | China |
|---|---|
| Brand | Bourns |
| Length | 4.45mm |
| Model | SRP4020TA |
| Depth | 1.8mm |
| Packaging | Reel |
| Series | SRP4020TA |
| Maximum Operating Temperature | 150°C |
| Minimum Operating Temperature | -55°C |
| Core Material | Carbonyl Powder |
| Inductance | 10μH |
| Standards/Approvals | RoHS |
| Package/Case | Surface Mount |
| Maximum DC Current | 1.8A |
| Maximum DC Resistance | 215mΩ |
| Inductance Tolerance | 20 % |
| Termination Style | Solder |
| Maximum Self Resonant Frequency | 19MHz |
| Minimum Quality Factor | 10 |
| Inductor Construction | Shielded |
| Automotive Standard | AEC-Q200 |
Key Features
- Compact surface mount package measuring 4.45 mm length and 1.8 mm depth.
- Shielded construction ensures reduced electromagnetic interference.
- Operating temperature range from -55°C to 150°C for robust performance.
- Maximum DC resistance is 215 mΩ to ensure efficiency.
- Meets automotive standard AEC-Q200 for reliability.
- RoHS compliant and moulded for durability and environmental safety.
- Maximum self-resonant frequency of 19 MHz suitable for high-frequency applications.
- Minimum quality factor of 10 for consistent inductive performance.
Product Description
Bourns SRP4020TA is a shielded multilayer surface mount inductor designed for electronic circuits requiring stable inductance and current handling capabilities. It utilizes a carbonyl powder core to deliver 10 μH inductance with a tolerance of 20%, making it suitable for filtering and energy storage applications in power electronics.
The inductor supports a maximum DC current of 1.8 A and exhibits a maximum DC resistance of 215 mΩ, balancing low power loss with thermal management. Its robust shielded construction minimizes electromagnetic interference, ensuring signal integrity in sensitive circuits.
Measuring 4.45 mm in length and 1.8 mm in depth, this component supports surface mount technology, enabling compact PCB designs. It operates reliably over a temperature range from -55°C up to 150°C, compliant with automotive standard AEC-Q200, thus suitable for automotive and industrial applications.
This inductor is RoHS certified and moulded, enhancing its environmental safety and mechanical durability. With a maximum self-resonant frequency of 19 MHz and a minimum quality factor of 10, it performs effectively in high-frequency filtering and signal processing tasks.
Typical use cases include power supply circuits, DC-DC converters, RF modules, and automotive electronic systems. The reel packaging facilitates high-volume manufacturing and automated assembly.
Compact surface mount package measuring 4.45 mm length and 1.8 mm depth. Shielded construction ensures reduced electromagnetic interference. Operating temperature range from -55°C to 150°C for robust performance. Maximum DC resistance is 215 mΩ to ensure efficiency.
Meets automotive standard AEC-Q200 for reliability. RoHS compliant and moulded for durability and environmental safety. Maximum self-resonant frequency of 19 MHz suitable for high-frequency applications. Minimum quality factor of 10 for consistent inductive performance.
Explore more components in the Surface Mount Inductors category at EnvMart for industrial, automotive, and commercial electronic design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has an inductance value of 10 μH with a tolerance of 20%.
It supports a maximum DC current of 1.8 A.
The inductor measures 4.45 mm in length and 1.8 mm in depth.
The maximum DC resistance is 215 mΩ, ensuring efficiency in operation.
It operates reliably over a temperature range from -55°C to 150°C.
The maximum self-resonant frequency is 19 MHz, making it suitable for high-frequency applications.
It meets the automotive standard AEC-Q200 for reliability.
Yes, it is RoHS compliant, ensuring it meets environmental safety standards.
The inductor utilizes a carbonyl powder core for its construction.
It has a minimum quality factor of 10, which supports consistent inductive performance.
It is packaged on a reel, facilitating high-volume manufacturing and automated assembly.
The termination style for this model is solder.
