TDK-Lambda DC/DC Converter 15V DC 1.33A 20W PCB Mount DIP Package PXD20-12S15
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | Converters / DC-DC Converters TDK-Lambda PXD DC/DC Converter, 15V dc/ 1 |
| Brand | TDK-Lambda |
| Efficiency | 0.85% |
| Length | 2in |
| Model | PXD20-12S15 |
| Depth | 10.2mm |
| Gross Weight | 27g |
| Width | 1in |
| Mount Type | PCB |
| Series | PXD |
| Maximum Operating Temperature | 85°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| MTBF | 2041000h |
| Number of outputs | 1 |
| Ripple and Noise | 75mV |
| Maximum Output Power | 20W |
| Maximum Input Voltage | 18V dc |
| Minimum Input Voltage | 9V dc |
| Number of Pins | 6 |
| Output Voltage 1 | 15V dc |
| Output Current 1 | 1.33A |
| Isolation Voltage | 1.6kV |
| Input Ratio | 2:1 |
| Input Ratio2 | 1 |
Key Features
- It features a DIP package type and a compact PCB mount form factor.
- Offers high isolation voltage of 1.6kV ensuring safety and noise reduction.
- Operates efficiently with 0.85% efficiency and a ripple and noise level of 75mV.
- Designed for a wide temperature range from -40°C to 85°C for robust industrial applications.
- Includes built-in short-circuit and over-voltage protection for reliability.
- The device has 6 pins and 1 output channel for straightforward integration.
- It has a MTBF of approximately 2,041,000 hours indicating high reliability.
Product Description
TDK-Lambda PXD20-12S15 DC/DC Converter is a high-performance power supply solution designed for electronic and industrial applications requiring 15V DC output at 1.33A with 20W power. Its PCB mount DIP package allows for efficient integration on compact circuit boards.
The converter operates over a 2:1 wide input voltage range of 9V to 18V DC, suitable for variable power inputs. It features a robust isolation voltage of 1.6kV that enhances electrical safety and reduces noise interference. Its ripple and noise rating of 75mV ensures clean power delivery critical for sensitive electronics.
Built-in protection against short-circuit and over-voltage conditions enhances operational stability and device longevity. With a maximum operating temperature of 85°C and a minimum of -40°C, this converter is suitable for harsh industrial, telecommunications, laboratory, and manufacturing environments.
Physical dimensions are 2 inches in length, 1 inch in width, and 10.2mm in depth, weighing just 27 grams, making it ideal for space-constrained designs. The device has 6 pins and provides a single output channel for straightforward use.
Key applications include powering sensitive electronics, precision instrumentation, control systems, and embedded power solutions in industrial and commercial settings. This converter supports a 2:1 wide input voltage range of 9V to 18V DC.
It features a DIP package type and a compact PCB mount form factor. Offers high isolation voltage of 1.6kV ensuring safety and noise reduction. Operates efficiently with 0.85% efficiency and a ripple and noise level of 75mV.
Designed for a wide temperature range from -40°C to 85°C for robust industrial applications. Includes built-in short-circuit and over-voltage protection for reliability. The device has 6 pins and 1 output channel for straightforward integration.
It has a MTBF of approximately 2,041,000 hours indicating high reliability. Dimensions are compact with length 2 inches, width 1 inch, and depth 10.2mm, and a weight of 27g. Explore EnvMart's Electronics & Electricals section for more TDK-Lambda converters and related power supply solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum output power of this model is 20W.
It operates over a 2:1 input voltage range of 9V to 18V DC.
This model has an efficiency rating of 0.85%.
The dimensions are 2 inches in length, 1 inch in width, and 10.2mm in depth.
The isolation voltage is 1.6kV, which enhances electrical safety and reduces noise interference.
It has one output channel.
The operating temperature range is from -40°C to 85°C.
This converter features a DIP package type suitable for PCB mounting.
The ripple and noise level is rated at 75mV.
It includes built-in short-circuit and over-voltage protection for enhanced reliability.
The weight of this model is 27 grams.
The mean time between failures (MTBF) is approximately 2,041,000 hours.
