TDK-Lambda PXD20-12D15 DC/DC Converter Dual Output 15V DC 670mA 20W PCB Mount DIP Package 85°C Max Temp
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | Converters / DC-DC Converters TDK-Lambda PXD DC/DC Converter, 15V dc/ 670 mA, 18 |
| Brand | TDK-Lambda |
| Efficiency | 0.86% |
| Length | 2in |
| Model | PXD20-12D15 |
| Depth | 10.2mm |
| Gross Weight | 27g |
| Width | 1in |
| Mount Type | PCB |
| Series | PXD |
| Maximum Operating Temperature | 85°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| MTBF | 2041000h |
| Number of outputs | 2 |
| Ripple and Noise | 100mV |
| Maximum Output Power | 20W |
| Maximum Input Voltage | 18V dc |
| Minimum Input Voltage | 9V dc |
| Number of Pins | 6 |
| Output Voltage 1 | 15V dc |
| Output Current 1 | 670mA |
| Isolation Voltage | 1.6kV |
| Output Current 2 | 0.67A |
| Input Ratio | 2:1 |
| Input Ratio2 | 1 |
| Output Voltage 2 | -15V dc |
Key Features
- Provides dual outputs including 15V DC and -15V DC for versatile power applications.
- Compact DIP package measuring 2 x 1 x 0.4 inches ensures easy integration into electronic circuits.
- Offers robust protections including short-circuit and over-voltage safeguards with 1600V DC isolation voltage.
- Operates reliably in a temperature range of -40°C to 85°C.
- High efficiency rated at approximately 86% to minimize energy loss.
- Mount type suitable for PCB installation with 6 pins for secure connections.
- MTBF rating of over 2 million hours ensuring long operational life.
- Designed and manufactured in Taiwan, Province Of China, complying with industry standards.
Product Description
TDK-Lambda PXD20-12D15 is a high-quality DC/DC converter module offering dual outputs with a nominal voltage of 15V DC at 670 mA and an inverted output of -15V DC. It supports a wide input voltage range between 9 V and 18 V DC, making it suitable for various power supply designs where regulated dual voltages are required.
This converter is housed in a compact DIP package with a footprint of 2 inches length, 1 inch width, and 10.2 mm depth, ideal for printed circuit board integration. The device features a 2:1 input ratio and six pins for mounting, providing reliable electrical connections for industrial and commercial electronic applications.
It is designed with high isolation of 1.6 kV DC to protect circuits from high voltage spikes and noise, and includes protections against short circuits and over-voltage conditions enhancing system reliability. The ripple and noise output is kept minimal at 100 mV to ensure clean power delivery to sensitive electronics.
The module operates efficiently with an efficiency rating around 86%, which reduces power losses and heat generation. Its operating temperature range spans from -40°C to 85°C, enabling performance stability in harsh environmental conditions.
Applications for the PXD20-12D15 include industrial automation, telecommunications, instrumentation, test and measurement equipment, and other areas requiring stable multiple DC voltages from a single supply source.
Wide input voltage range from 9 to 18 V DC ensuring versatility. Dual output voltages provide both positive and negative 15 V DC supplies. Compact DIP package simplifies PCB mounting and integration. High isolation voltage of 1600 V DC protects sensitive electronics.
Low ripple and noise output enhances power quality. Robust short-circuit and over-voltage protection mechanisms. High efficiency reduces power wastage and thermal load. Extended operating temperature range for reliable performance.
Long MTBF of over 2 million hours for dependable operation.
This product is ideal for designers and engineers looking for a reliable power converter to integrate into complex electronic systems. Explore the wide range of DC/DC Converters from TDK-Lambda available in EnvMart to find the perfect match for your industrial or commercial applications.
