onsemi 2 Monostable Multivibrator 2.4 mA 16-Pin TSSOP MC14538BDTR2G
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 1.05mm |
| Length | 5.1mm |
| Model | MC14538BDTR2G |
| Mount Type | Surface |
| Series | MC14538 |
| Maximum Operating Temperature | 125°C |
| Package Type | TSSOP |
| Minimum Operating Temperature | -55°C |
| Pin Count | 16 |
| Number of Elements per Chip | 2 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 18V |
| Logic Family | MC |
| Minimum Supply Voltage | 3V |
| Maximum High Level Output Current | -0.36mA |
| Maximum Propagation Delay Time @ CL | 600ns |
| Maximum Low Level Output Current | 2.4mA |
| Minimum Pulse Width | 10μs |
| Maximum Quiescent Current | 700μA |
| Multivibrator Type | Monostable Multivibrator |
| Wide operating voltage range | 3 to 18V |
Key Features
- Operates over a wide voltage range from 3 V to 18 V.
- Features a minimum pulse width of 10 microseconds to support precise timing applications.
- Designed for surface mount applications with low quiescent current of 700 microamperes.
- Supports operation in temperature range from -55°C to 125°C.
- Maximum propagation delay time of 600 nanoseconds at specified load capacitance.
- Complies with automotive standard AEC-Q100 for robust automotive use.
- Compact dimensions with a length of 5.1 mm and height of 1.05 mm.
- Ideal for use in electronic circuits requiring monostable timing and pulse generation.
Product Description
onsemi MC14538BDTR2G is a monostable multivibrator IC featuring two elements per chip, designed for surface mount applications in a compact 16-pin TSSOP package. It operates within a wide supply voltage range of 3 V to 18 V, making it versatile for various power environments. The device draws a low supply current of 2.4 mA and exhibits a very low quiescent current of 700 microamperes, contributing to power-efficient circuit designs.
The IC supports a minimum pulse width as short as 10 microseconds, suitable for precise timing control in industrial, automotive, and electronic equipment. It has a maximum propagation delay time of 600 nanoseconds under standard load capacitance, enabling fast switching and response within electronic systems.
The MC14538BDTR2G is qualified to the AEC-Q100 automotive standard, ensuring suitability for use in automotive environments with rigorous quality and reliability demands. It is designed to operate across a broad temperature range from -55°C to 125°C, supporting harsh environmental conditions.
This device is compact with a length of 5.1 mm and height of 1.05 mm, facilitating integration into space-constrained PCB layouts. Typical applications include timing pulse generation, waveform shaping, and monostable multivibrator functions used in industrial control, automotive electronics, instrumentation, and communication equipment.
Wide operating voltage range: 3 V to 18 V for flexible power usage. Low quiescent current: 700 microamperes for power savings. Minimum pulse width 10 microseconds for accurate timing. Maximum propagation delay of 600 nanoseconds enabling fast response.
Automotive grade AEC-Q100 certification for reliability. Surface mount TSSOP package with 16 pins for compact electronic designs. Operating temperature range from -55°C to 125°C for harsh environments.
This product is a reliable component for monostable multivibrator functions and timing pulse generation within various industrial and automotive electronic applications. Browse the Semiconductor category on EnvMart for more onsemi logic IC solutions and related components.
Explore more products in our Monostable Multivibrators category.
