onsemi 2 Monostable Multivibrator 2.4 mA, 16-Pin SOIC MC14528BDR2G

onsemi MC14528BDR2G is a 2 Element Monostable Multivibrator logic IC designed for robust timing and pulse generation applications. Packaged in a 16-Pin SOIC surface mount form factor, it supports a wide operating voltage from 3 V up to 18 V, making it ideal for versatile electronics system designs. The device excels with a minimum pulse width of 10 microseconds and minimal quiescent current, ensuring efficient power usage in your projects.

Operating effectively within a wide temperature range from -55°C to 125°C, this multivibrator IC meets automotive standards including AEC-Q100, signifying its reliability in harsh environments. With a maximum propagation delay time of 1 microsecond under standard load, it provides precise timing control essential for industrial automation, automotive electronics, and consumer devices.

The MC14528BDR2G belongs to the MC series, known for their CMOS logic family devices tailored for timing and multivibrator applications in electronics and semiconductor markets. The compact 1.5 mm height and 10 mm length SOIC package ensures easy integration onto modern PCBs while maintaining durability.

Applications include pulse generation, timing delay circuits, and other electronics requiring controlled monostable pulse outputs. Its surface mount design facilitates efficient automated assembly and high-density electronic designs.

This device belongs to the MC logic family providing 2 elements per chip. Supports a wide supply voltage range from 3 V to 18 V. Offers minimum pulse width of 10 microseconds for precise timing applications. Operates reliably over a temperature range from -55°C to 125°C.

Surface mount package with SOIC type and compact dimensions for flexible PCB design. Features low quiescent current for energy-efficient operation. Automotive standard compliant with AEC-Q100 certification. Maximum propagation delay time of 1 microsecond at load capacitance.

Suitable for industrial, automotive, and consumer electronic timing circuits. Robust construction with a height of 1.5 mm and length of 10 mm for durable installations. Explore more semiconductor logic ICs and Monostable Multivibrators at EnvMart for your industrial, automotive, and electronic component needs.
