Weidmüller Pluggable Terminal Block, BC 3.81 Series, 4-Contact, 3.81 mm Pitch, 1 Row, 320 V, 17.5 A, Nylon 1798550000
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 320V |
| Brand | Weidmüller |
| Colour | Black |
| Orientation | Right Angle |
| Current | 17.5A |
| Length | 15.24mm |
| Depth | 19.1mm |
| Width | 10.5mm |
| Housing Material | Nylon |
| Series | BC 3.81 |
| Number of Rows | 1 |
| Pitch | 3.81mm |
| Standards/Approvals | RoHS |
| Number of Contacts | 4 |
| Connector Gender | Male |
| Minimum Wire Size mm² | 2mm² |
| Maximum Wire Size mm² | 1.5mm² |
| Minimum Wire Size AWG | 28AWG |
| Maximum Wire Size AWG | 16AWG |
| Wire Connection Method | Screw |
Key Features
- Maximum continuous current rating of 17.5 A ensures reliable conductivity.
- Constructed with durable black nylon housing for enhanced insulation.
- Screw connection mechanism facilitates secure and maintainable wiring.
- Right angle orientation optimizes PCB layout and assembly flexibility.
- Compatible with wire sizes ranging from 28 to 16 AWG and 0.2 to 1.5 mm².
- Compact dimensions with length 15.24 mm, width 10.5 mm, and depth 19.1 mm.
- Designed to comply with RoHS standards for environmental safety.
Product Description
Weidmüller 1798550000 pluggable terminal block, part of the BC 3.81 series, is engineered for secure and flexible electrical connections in industrial environments. It features a 4-contact configuration arranged in a single row with a 3.81 mm pitch, making it ideal for compact and precise circuit designs.
The terminal block supports a voltage rating of 320 V and a current rating of 17.5 A, suitable for a variety of industrial, manufacturing, automation, and electronic applications. Its black nylon housing provides strong insulation and mechanical stability, while the screw connection method allows for a reliable and maintainable conductor clamp.
The right angle orientation is designed to optimize PCB footprint and wiring accessibility. It accepts wire sizes from 28 AWG (0.2 mm²) up to 16 AWG (1.5 mm²), accommodating flexible cabling requirements.
Rated voltage: 320 V for safe operation. Current carrying capacity: 17.5 A ensuring effective power transmission. Durable nylon housing for insulation and protection. Screw clamp mechanism for dependable wire connection.
Compact size with length 15.24 mm, width 10.5 mm, depth 19.1 mm. Right angle connector orientation for PCB space optimization. RoHS compliant, meeting environmental regulations. Supports wire sizes 28 AWG to 16 AWG.
This terminal block is suitable for use in electronics components assemblies, industrial automation systems, power distribution boards, and various electrical connector setups requiring compact and reliable pluggable terminals.
Explore the wide range of Pluggable Terminal Blocks and electrical connectors available to find components tailored to your specific project needs on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous current rating of this model is 17.5 A, ensuring reliable conductivity in electrical applications.
This terminal block has a voltage rating of 320 V, making it suitable for various industrial applications.
It is compatible with wire sizes ranging from 28 AWG (0.2 mm²) to 16 AWG (1.5 mm²), accommodating flexible cabling requirements.
The dimensions of this model are 15.24 mm in length, 10.5 mm in width, and 19.1 mm in depth.
It features a screw connection mechanism, which facilitates secure and maintainable wiring.
The terminal block is designed with a right angle orientation, optimizing PCB layout and assembly flexibility.
The housing is constructed from durable black nylon, providing strong insulation and mechanical stability.
Yes, it is designed to comply with RoHS standards for environmental safety.
This model features a 4-contact configuration arranged in a single row.
It is part of the BC 3.81 series, which is engineered for compact and precise circuit designs.
This terminal block is suitable for use in electronics components assemblies, industrial automation systems, and power distribution boards.
The connector gender of this model is male, designed for secure electrical connections.
