Weidmüller OMNIMATE SC Series Pluggable Terminal Block, 6-Contact, 3.81 mm Pitch, 1 Row, 320 V, 17.5 A, Glass 1863020000
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 320V |
| Brand | Weidmüller |
| Colour | Black |
| Orientation | Straight |
| Current | 17.5A |
| Length | 12.4mm |
| Depth | 7.07mm |
| Width | 23.55mm |
| Housing Material | Glass Filled Liquid Crystal Polymer |
| Series | OMNIMATE SC |
| Number of Rows | 1 |
| Pitch | 3.81mm |
| Standards/Approvals | IEC 60664-1, IEC 61984 |
| Number of Contacts | 6 |
| Connector Gender | Male |
| Wire Connection Method | Solder |
Key Features
- Rated for 320 V voltage and 17.5 A current capacity.
- Constructed with glass filled liquid crystal polymer housing for enhanced durability.
- Male connector gender with straight orientation for ease of installation.
- Wire connection achieved by solder method ensuring stable connections.
- Complies with IEC 60664-1 and IEC 61984 standards for safety and reliability.
- Black color coding for easy identification in assemblies.
Product Description
Weidmüller 1863020000 OMNIMATE SC Series Pluggable Terminal Block is a high-quality connector designed for industrial and electronic power connectivity applications. With 6 contacts arranged in a single row and a 3.81 mm pitch, this terminal block is engineered to handle up to 17.5 A current and operate reliably at 320 V. The housing material is a robust glass filled liquid crystal polymer, providing excellent mechanical strength and chemical resistance, ideal for demanding environments.
This pluggable terminal block features a male connector with a straight orientation to facilitate straightforward solder wire connection, ensuring a secure and durable electrical interface. Its compact dimensions (12.4 mm length, 23.55 mm width, 7.07 mm depth) make it suitable for space-constrained PCBs and control panels. This terminal block conforms to IEC 60664-1 and IEC 61984 standards, guaranteeing compliance with international safety and quality requirements.
Typical use cases include industrial automation, power supply systems, electronic instrumentation, and control cabinet assemblies where reliable and modular terminal solutions are essential. The black color coding aids visual identification, enabling organized wiring layouts.
Rated for 320 V voltage and 17.5 A current capacity. Made from high-quality glass filled liquid crystal polymer housing. Single row, 6-contact configuration with 3.81 mm pitch. Male connector gender with straight orientation.
Wire connection via solder method for robust electrical contact. Complies with IEC 60664-1 and IEC 61984 standards. Compact size ensures suitability for dense PCB designs.
Weidmüller's OMNIMATE series is well regarded in the industrial electronics field for offering reliable terminal solutions adaptable to a wide range of applications. Explore additional Weidmüller products and related Pluggable Terminal Blocks on EnvMart to meet your connectivity requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a voltage of 320 V and a current capacity of 17.5 A.
The contacts in this pluggable terminal block are arranged with a pitch of 3.81 mm.
It features 6 contacts arranged in a single row.
The wire connection is achieved through a solder method, ensuring stable connections.
The dimensions are 12.4 mm in length, 23.55 mm in width, and 7.07 mm in depth.
The housing is constructed from glass filled liquid crystal polymer, providing enhanced durability.
This model has a male connector with a straight orientation for ease of installation.
It complies with IEC 60664-1 and IEC 61984 standards for safety and reliability.
The terminal block features black color coding for easy identification in assemblies.
Typical applications include industrial automation, power supply systems, and control cabinet assemblies.
It is manufactured in Germany.
This terminal block belongs to the OMNIMATE SC Series.
