Bourns 0805 Unshielded Surface Mount Inductor with Ferrite DR Core 68 μH ±10% 850 mA IDC Q15 SDR0805
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 7.8mm |
| Brand | Bourns |
| Height | 5.3mm |
| Length | 7.8mm |
| Model | SDR0805 |
| Depth | 7.8mm |
| Packaging | Reel |
| Series | SDR0805 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite DR |
| Inductance | 68μH |
| Standards/Approvals | RoHS |
| Package/Case | 0805 |
| Maximum DC Current | 850mA |
| Maximum DC Resistance | 300mΩ |
| Inductance Tolerance | ±10 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 8MHz |
| Minimum Quality Factor | 15 |
| Inductor Construction | Wirewound |
Key Features
- Compact 0805 package with 7.8 mm diameter and 5.3 mm height.
- Wirewound construction with ferrite DR core enhances performance.
- Inductance tolerance ±10% ensures precision.
- Maximum DC resistance of 300 mΩ limits power loss.
- RoHS compliant and suitable for automotive and industrial applications.
- Maximum operating temperature of 125°C supports harsh environments.
- Surface mount termination style for easy PCB assembly.
- Maximum self-resonant frequency of 8 MHz and minimum quality factor of 15.
Product Description
The Bourns SDR0805 model is an 0805 unshielded surface mount inductor featuring a ferrite DR core designed for high-reliability electronic circuits.
This inductor provides a nominal inductance of 68 μH with a tolerance of ±10%, making it suitable for a variety of power management, filtering, and signal conditioning applications.
It supports a maximum DC current of 850 mA with a maximum DC resistance of 300 mΩ, ensuring energy-efficient operation with minimal power loss.
Constructed with a wirewound design and molded with precision, the component measures 7.8 mm in diameter, 5.3 mm in height, and fits within the 0805 package size for compact surface mount assembly.
The inductor operates reliably within a temperature range from -40°C to 125°C and meets RoHS standards, enabling its use in automotive, industrial, and consumer electronics sectors.
Additional technical features include a maximum self-resonant frequency of 8 MHz and a minimum quality factor (Q) of 15, which contribute to its effective filtering and impedance characteristics.
Compact 0805 package with precise wirewound construction. High quality ferrite DR core for consistent inductance. Broad operating temperature range supporting harsh environments. RoHS compliant for environmentally sensitive applications.
Ideal for power supplies, DC/DC converters, and EMI/RFI filtering.
This Bourns SDR0805 surface mount inductor is widely used in industrial, automotive, electronic manufacturing, and HVAC control systems requiring reliable inductive components in miniature form factors.
Explore more high-performance electronic components within the Surface Mount Inductors category at EnvMart for your design and production needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a nominal inductance of 68 μH with an inductance tolerance of ±10%.
The maximum DC current rating for this inductor is 850 mA.
It has a maximum DC resistance of 300 mΩ, which helps limit power loss during operation.
This inductor measures 7.8 mm in diameter and 5.3 mm in height, fitting within the 0805 package size.
The maximum operating temperature is 125°C, allowing it to function in harsh environments.
The minimum operating temperature for this inductor is -40°C.
The maximum self-resonant frequency is 8 MHz, contributing to its effective filtering capabilities.
It has a minimum quality factor (Q) of 15, which enhances its performance in filtering applications.
The core material is a ferrite DR, which is designed for high reliability in electronic circuits.
This inductor features a surface mount termination style, facilitating easy PCB assembly.
Yes, it is RoHS compliant, making it suitable for environmentally sensitive applications.
This model is suitable for power management, filtering, and signal conditioning applications in automotive and industrial sectors.
