Murata Wirewound Surface Mount Inductor 100 nH ±2% 220mA 0603 Package with Ferrite Core LQW18ANR10G00D

Murata LQW18ANR10G00D wirewound surface mount inductor is engineered with a ferrite core and designed specifically for electronic applications requiring compact and efficient magnetic components. The inductor provides an inductance of 100 nH with a tight tolerance of ±2%, making it suitable for precision applications at very high frequencies.

Its compact 0603 package with dimensions of 1.6 mm length, 0.8 mm height, and 0.8 mm depth supports high-density surface mount circuits. The maximum DC current rating of 220 mA along with a low DC resistance of 680 milliohms ensures stable operation in demanding conditions. The minimum quality factor of 34 indicates excellent frequency response performance, making it ideal for wireless telecommunication circuits such as Bluetooth, GSM, and WLAN.

The inductor is moulded and uses solder termination style to facilitate reliable solder connections. Operating temperature ranges from -55°C to 125°C ensure suitability in both industrial and commercial electronics.

This component is packaged in paper tape format designed for automated assembly lines which improves production efficiency. Ferrite core for high permeability and low loss magnetic performance. Wirewound construction ensuring durability and consistent inductance.

High self-resonant frequency of 1.8 GHz supporting VHF and UHF bands. Non-shielded design to suit applications tolerant to EMI. Two-pin count surface mount device optimized for compact PCB footprints. Suitable for use in telecommunications, industrial electronics, and consumer devices requiring high frequency inductors.

This product is part of Murata’s LQW18AN series specialized for high frequency circuit applications. It is ideal for engineers and designers seeking reliable inductors with tight tolerances and high quality factor for demanding surface mount assemblies.
