Bourns 1210 Unshielded Wirewound Surface Mount Inductor with Ferrite Core 47 μH ±10% 75 mA Idc Q30 CM322522
Specifications
| Country of Origin | India |
|---|---|
| Brand | Bourns |
| Height | 2.2mm |
| Length | 3.2mm |
| Model | CM322522 |
| Depth | 2.5mm |
| Packaging | Tape & Reel |
| Series | CM322522 |
| Maximum Operating Temperature | 100°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 47μH |
| Standards/Approvals | RoHS |
| Package/Case | 1210 |
| Maximum DC Current | 75mA |
| Pin Count | 2 |
| Maximum DC Resistance | 7Ω |
| Inductance Tolerance | ±10 % |
| Termination Style | Solder |
| Maximum Self Resonant Frequency | 15MHz |
| Minimum Quality Factor | 30 |
| Inductor Construction | Wirewound |
Key Features
- This inductor has a maximum DC current rating of 75 mA.
- It features a Q factor of 30 for efficient frequency performance.
- The package size is 1210 with dimensions of 3.2 mm length, 2.5 mm depth, and 2.2 mm height.
- Core material is ferrite and the inductor construction is wirewound with solder termination.
- Rated for a maximum operating temperature of 100°C and minimum of -40°C, suitable for various environments.
- The component is tape and reel packaged for manufacturing efficiency.
- It complies with RoHS standards and has a maximum DC resistance of 7 Ω.
- The maximum self-resonant frequency of this inductor is 15 MHz, making it suitable for high frequency applications.
Product Description
Bourns CM322522 1210 unshielded wirewound surface mount inductor with ferrite core features 47 μH inductance with ±10% tolerance and a low maximum DC current of 75 mA. Designed with a wirewound construction and resin molding, the inductor offers reliable performance in electronic circuits requiring inductance within surface mount technology form factors.
Its compact 1210 package measuring 3.2 mm in length, 2.5 mm in depth, and 2.2 mm in height supports space-saving PCB designs. The ferrite core enhances magnetic performance while maintaining low DC resistance at 7 Ω. The solder termination style ensures strong mechanical bond and electrical connectivity.
Operating temperature range from -40°C to 100°C allows integration in diverse industries including consumer electronics, wireless communication, and AV equipment. The inductor's quality factor of 30 and maximum self-resonant frequency of 15 MHz enable efficient filtering and signal conditioning in high frequency circuits.
This product is tape and reel packaged to support automated assembly processes, improving production throughput and component handling. Additionally, it meets RoHS environmental standards, suitable for regulated manufacturing environments.
This inductor features a ferrite core for improved magnetic characteristics. Its wirewound construction provides consistent inductance and high-quality factor. Maximum DC current is limited to 75 mA to ensure circuit protection.
Compact dimensions fit tightly in space-sensitive designs. Designed for operation in temperatures from -40°C to 100°C. Solder termination style offers reliable circuit board mounting. Packaged in tape & reel format facilitating automated PCB assembly.
RoHS compliant for environmentally conscious manufacturing.
Typical applications include industrial and consumer electronics, wireless devices, and AV equipment requiring compact inductors for signal filtering and energy storage. This Bourns surface mount inductor combines precision engineering and robust construction for dependable performance in demanding electronic environments.
Explore more Surface Mount Inductors and electronic components on EnvMart for optimizing your PCB designs and manufacturing workflow.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductor has an inductance value of 47 μH with a tolerance of ±10%.
It has a maximum DC current rating of 75 mA.
The dimensions of the 1210 package are 3.2 mm in length, 2.5 mm in depth, and 2.2 mm in height.
The maximum self-resonant frequency is 15 MHz.
It operates within a temperature range of -40°C to 100°C.
The core material is ferrite, which enhances magnetic performance.
It features a solder termination style for reliable circuit board mounting.
It is packaged in tape and reel format to support automated assembly processes.
The maximum DC resistance is 7 Ω.
The minimum quality factor is 30, indicating efficient frequency performance.
Yes, it complies with RoHS standards, making it suitable for environmentally conscious manufacturing.
This inductor is suitable for applications in consumer electronics, wireless communication, and AV equipment.
