Celduc Solid State Relay SO867970, SO8 Series, 90 A Load, 510 Vrms Maximum Load Voltage, DIN Rail Mount, 265V Control Voltage

Celduc SO867970 Solid State Relay from the SO8 Series is designed for industrial and commercial electrical control applications offering reliable switching performance with a 90 A maximum load current capacity. This DIN rail mounted relay supports a maximum load voltage of 510 Vrms, making it suitable for heavy-duty single-phase loads.

It features zero cross switching to reduce electrical disturbances and an on-state resistance of 16 milliohms ensuring efficient conduction. The relay’s screw terminal ensures a secure electrical connection, while its IP20 rating protects against solid objects, suitable for indoor electrical panels.

Operating temperature ranges from -40°C to 100°C, allowing it to perform reliably in varied industrial environments. The input voltage controls up to 265V AC/DC with a wide control range of 3 to 32 Vdc supported by a regulated control current. A green LED input display facilitates easy monitoring of operational status.

This single-pole single-throw (SPST) solid state relay incorporates triac output switching technology designed for instantaneous switching operations.

The product complies with stringent international safety and quality standards including VDE, UKCA, RoHS, EAC, cURus, CSA, and CE, ensuring durability and regulatory compliance. Manufactured in France, this relay is suitable for use in industrial automation, manufacturing, HVAC control systems, water treatment plants, and other heavy-duty control applications.

Supports maximum load voltage of 510 Vrms ensuring compatibility with high voltage circuits. Controlled by 265V input voltage with zero cross switching function for reduced electrical noise. Compact dimensions of 58.5 mm length, 44.8 mm width, and 30 mm height allow space-efficient installations.

Built with IP20 rated enclosure providing basic protection against solid objects. Equipped with screw terminal type for secure and reliable connections. Operates effectively in temperature range from -40°C up to 100°C suitable for harsh environments.

Low on-state resistance of 16 milliohms reduces power loss and heating during operation. Features green LED input display for easy status indication. Designed for single-phase AC loads with SPST contact configuration using triac output type.

Manufactured in France, meeting international standards including VDE, UKCA, RoHS, EAC, cURus, CSA, and CE certifications. Explore a wide range of Solid State Relays and DIN rail mounted electrical components at EnvMart for your industrial and automation needs.
