Weidmüller BL Series Pluggable Terminal Block 12-Contact 3.5 mm Pitch 320V 14.5A Female Tension Clamp Spring 1690290000
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 320V |
| Brand | Weidmüller |
| Colour | Orange |
| Orientation | 180° |
| Current | 14.5A |
| Depth | 22mm |
| Width | 42mm |
| Housing Material | Polybutylene Terephthalate |
| Series | BL |
| Number of Rows | 1 |
| Pitch | 3.5mm |
| Number of Contacts | 12 |
| Connector Gender | Female |
| Minimum Wire Size mm² | 0.13mm² |
| Maximum Wire Size mm² | 1.5mm² |
| Minimum Wire Size AWG | 28AWG |
| Maximum Wire Size AWG | 16AWG |
| Wire Connection Method | Tension Clamp Spring |
Key Features
- Supports a current rating of 14.5 amperes for heavy-duty applications.
- Designed with a single row configuration for space efficiency.
- Compatible with wire sizes from 0.13 mm² to 1.5 mm² and 28 AWG to 16 AWG.
- Constructed with durable Polybutylene Terephthalate housing in bright orange color.
- Equipped with female connector gender and tension clamp spring wire connection method.
- Operates at a voltage of 320 volts with a 180° wire orientation.
- Compact dimensions of 42 mm width and 22 mm depth for easy installation.
- Manufactured to the BL series specifications ensuring consistency and reliability.
Product Description
Weidmüller 1690290000 Pluggable Terminal Block is a high-performance 12-contact connector designed for industrial and electronic component applications. This single-row terminal block features a 3.5 mm pitch and a robust housing made from Polybutylene Terephthalate, providing excellent durability and resistance in electrical installations.
The product supports a current rating of 14.5 amperes and operates at a voltage rating of 320 volts, making it suited for power distribution and control circuits in industrial environments. It supports a wide wire size range from 0.13 mm² to 1.5 mm² (28 AWG to 16 AWG), secured via a reliable tension clamp spring mechanism that ensures low contact resistance and secure connections.
The terminal block's design includes a female connector gender and 180° wire orientation for versatile mounting and wiring flexibility. It has compact dimensions with a width of 42 mm and a depth of 22 mm, enabling installation in tight spaces on PCBs or DIN rails.
This BL series Pluggable Terminal Block from Weidmüller complies with industrial flammability and material standards, though it does not carry specific formal approvals. Made in Germany, it is ideal for use in industrial automation, manufacturing equipment, control panels, and electrical power distribution systems.
Current rating of 14.5A suitable for demanding electrical loads. Housing material ensures mechanical strength and heat resistance. Supports a broad range of wire sizes for flexible connections. Tension clamp spring method provides secure and corrosion-resistant wire retention.
Compact size facilitates efficient PCB or panel space utilization. Distinct orange color aids visual identification and labelling. Single-row, 12-contact design offers reliable multi-connection support.
This product is an excellent choice for engineers and technicians requiring a durable, dependable terminal block for power connectors in electronic circuits and industrial automation systems. It complements the Weidmüller Omnimate range, known for cost efficiency and space-saving designs.
Explore more Weidmüller connectivity solutions and related industrial electronics at EnvMart, your reliable partner for quality electrical components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a current rating of 14.5 amperes, making it suitable for heavy-duty applications.
The terminal block operates at a voltage rating of 320 volts.
It is compatible with wire sizes ranging from 0.13 mm² to 1.5 mm² and 28 AWG to 16 AWG.
The contact pitch is 3.5 mm, designed for efficient space utilization.
The wire connection orientation is 180°, allowing for versatile mounting options.
The housing is constructed from Polybutylene Terephthalate, which provides durability and resistance in electrical installations.
It has compact dimensions of 42 mm in width and 22 mm in depth, facilitating installation in tight spaces.
This model features 12 contacts in a single-row configuration.
It uses a tension clamp spring wire connection method, ensuring secure and low-resistance connections.
This terminal block is manufactured in Germany.
It is available in a bright orange color, aiding in visual identification and labeling.
It is suitable for applications in industrial automation, manufacturing equipment, control panels, and electrical power distribution systems.
