Phoenix Contact Pluggable Terminal Block 3-Contact 5.08 mm Pitch Surface Mount 320V 12A 1861247
Specifications
| Country of Origin | Poland |
|---|---|
| Voltage | 320V |
| Brand | Phoenix Contact |
| Colour | Green |
| Orientation | Straight |
| Current | 12A |
| Length | 23.7mm |
| Model | 1861247 |
| Depth | 14.3mm |
| Width | 15.11mm |
| Mount Type | Surface |
| Housing Material | Polybutylene Terephthalate |
| Number of Rows | 1 |
| Pitch | 5.08mm |
| Standards/Approvals | IEC |
| Number of Contacts | 3 |
| Minimum Wire Size mm² | 0.2mm² |
| Maximum Wire Size mm² | 2.5mm² |
| Minimum Wire Size AWG | 24AWG |
| Maximum Wire Size AWG | 12AWG |
| Wire Connection Method | Screw |
Key Features
- Supports a nominal current of 12 amperes for robust performance.
- Compact surface mount design with dimensions 23.7 mm length, 15.11 mm width, and 14.3 mm depth.
- Constructed from durable Polybutylene Terephthalate housing material in green color for easy identification.
- Wires connect via screw method supporting wire sizes from 0.2 mm² to 2.5 mm², or AWG 24 to AWG 12.
- Complies with IEC standards ensuring quality and safety.
- Single row configuration for simple integration into PCB assemblies.
- Offers time-saving push-in connection and color-coded actuation lever for intuitive use.
Product Description
Phoenix Contact 1861247 is a pluggable terminal block designed for electronic applications requiring secure and efficient PCB connections. Featuring a 3-contact configuration with a 5.08 mm pitch and surface mount installation, this device supports a nominal current rating of 12A and voltage rating of 320V (III/2).
The housing, made from Polybutylene Terephthalate, offers durability and is color-coded green for quick visual identification. Wire connections are secured by screw method, accommodating wire sizes ranging from 0.2 mm² to 2.5 mm² (24 AWG to 12 AWG), ensuring compatibility with a wide range of wiring standards.
Compact dimensions of length 23.7 mm, width 15.11 mm, and depth 14.3 mm make it suitable for tightly packed PCB layouts. The product is certified to meet IEC standards, guaranteeing performance compliance and safety.
This terminal block integrates features such as time-saving push-in connection technology requiring no tools, a color-coded actuation lever for user-friendliness, and an integrated test option to facilitate convenient electrical testing and maintenance.
Ideal for industrial, automation, manufacturing, and power distribution applications, it can be combined with the MSTB 2.5 product range to fulfill complex circuit requirements. Supports a nominal current of 12 amperes for robust performance.
Rated voltage of 320 volts ensuring safe operation under standard conditions. Compact surface mount design with dimensions 23.7 mm length, 15.11 mm width, and 14.3 mm depth. Constructed from durable Polybutylene Terephthalate housing material in green color for easy identification.
Wires connect via screw method supporting wire sizes from 0.2 mm² to 2.5 mm², or AWG 24 to AWG 12. Complies with IEC standards ensuring quality and safety. Single row configuration for simple integration into PCB assemblies.
Offers time-saving push-in connection and color-coded actuation lever for intuitive use. This product is made in Poland and offered in new condition. Browse more in our Pluggable Terminal Block category at EnvMart for compatible industrial electrical components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a nominal current rating of 12 amperes.
The voltage rating is 320 volts.
The dimensions are 23.7 mm in length, 15.11 mm in width, and 14.3 mm in depth.
It accommodates wire sizes ranging from 0.2 mm² to 2.5 mm², or AWG 24 to AWG 12.
The housing is constructed from Polybutylene Terephthalate.
Wires connect via a screw method, ensuring a secure connection.
The pitch is 5.08 mm.
Yes, it complies with IEC standards, ensuring quality and safety.
The orientation is straight.
It has 3 contacts.
It is made in Poland.
It is designed for surface mounting.
