Bourns 1210 Shielded Wirewound Surface Mount Inductor 33 μH ±20%, 4.4 A DC Current, Ferrite DR & RI Core SRR1210

Bourns SRR1210 shielded wirewound surface mount inductor is designed for electronic applications requiring reliable inductance of 33 μH with a tolerance of ±20% and a current rating of 4.4 A DC. Encapsulated in a compact 1210 package with dimensions of 12 mm length, 12 mm depth, and 10 mm height, it features a solder termination style suitable for surface mounting on PCBs.

This inductor uses a ferrite DR & RI core providing excellent magnetic properties and shielding to reduce electromagnetic interference. Its maximum DC resistance of 52 milliohms ensures efficient current conduction with minimal losses.

Operating within a wide temperature range from -40°C to 125°C, it suits demanding industrial and commercial electronic environments. With a minimum quality factor of 16 and a maximum self-resonant frequency of 6.5 MHz, it provides stable performance in high-frequency power supplies and DC/DC converters.

It conforms to RoHS environmental standards, making it a compliant choice for green electronics manufacturing. Packaged as tape and reel, SRR1210 supports automated pick-and-place assembly lines, improving production efficiency.

Applications include portable communication equipment, camcorders, LCD TVs, and other consumer electronics requiring dependable inductor components. Constructed with a ferrite DR & RI shielded core for EMI reduction. 1210 surface mount size supports dense PCB layouts.

Temperature range of -40°C to 125°C ensures wide usability. Low DC resistance minimizes energy loss during operation. RoHS compliant design suitable for environmentally sensitive applications. High current rating of 4.4 A for demanding electrical loads.

Tape and reel packaging facilitates automated assembly. Explore the full range of Surface Mount Inductors and other passive electronic components at EnvMart for industrial, laboratory, and manufacturing applications.
