Cosel DC/DC Converter , 15V DC Output, 13.5A Output Current, 24V DC Max Input, 202.5W Power, PCB Mount, DIP CHS3002415-B
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | Converters / DC-DC Converters Cosel CHS DC/DC Converter, 15V dc/ 13 |
| Brand | Cosel |
| Efficiency | 93.5% |
| Length | 58.9mm |
| Model | CHS3002415-B |
| Depth | 12.7mm |
| Gross Weight | 50g |
| Width | 12.7mm |
| Mount Type | PCB |
| Series | CHS |
| Maximum Operating Temperature | 85°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 1 |
| Ripple and Noise | 300mV Pk-Pk |
| Maximum Output Power | 202.5W |
| Maximum Input Voltage | 24V dc |
| Maximum Switching Frequency | 170kHz |
| Minimum Input Voltage | 18V |
| Number of Pins | 8 |
| Output Voltage 1 | 15V dc |
| Output Current 1 | 13.5A |
| Isolation Voltage | 1kV ac |
| High reliability | no built-in aluminium and tantalum electrolytic capacitor |
Key Features
- Provides a stable 15V DC output voltage with adjustable range.
- Supports a maximum output current of 13.5A suitable for demanding loads.
- Accepts a wide input voltage range from 18V to 24V DC for versatile usage.
- Built with a DIP package and PCB mounting type for easy integration.
- Operates efficiently at 93.5% with a maximum switching frequency of 170kHz.
- Compact size with dimensions 58.9mm length, 12.7mm width, and 12.7mm depth.
- Ensures high reliability by excluding aluminium and tantalum electrolytic capacitors.
- Features remote sensing, remote On/Off, overcurrent and overvoltage protection functions.
Product Description
Cosel CHS3002415-B DC/DC Converter offers a compact and efficient solution for converting 24V DC input down to a stabilized 15V DC output with a maximum current rating of 13.5A and power output of 202.5W. This PCB-mounted converter is designed in a DIP package to facilitate seamless integration on printed circuit boards.
With a compact footprint measuring 58.9mm by 12.7mm by 12.7mm, it delivers high efficiency of 93.5% with a switching frequency up to 170kHz, making it suitable for telecom and industrial applications where space and performance are critical.
The CHS series is distinguished by its high reliability, running without aluminium and tantalum electrolytic capacitors, which effectively enhances service life and reduces maintenance needs. Additionally, this model incorporates remote sensing and remote On/Off capabilities, along with protections against overcurrent and overvoltage conditions to safeguard downstream equipment.
It operates reliably across a broad temperature range from -40°C up to 85°C, allowing deployment in varied environmental conditions including industrial, telecommunications, and power management systems.
Features like 1kV AC isolation voltage and low ripple noise of 300mV peak-to-peak further increase the suitability of this converter for sensitive electronics and industrial control circuits requiring robust, noise-free power conversion.
Country of origin is Japan, and the converter complies with major safety and quality standards including UL 60950-1, CE, cUL CSA 60950-1, EN 60950-1, and cULus. Provides stable 15V DC output for precise voltage supply. Supports 13.5A output current for high power demands.
Accommodates input voltage range of 18V to 24V DC. Robust PCB mount and DIP package design for easy installation. High efficiency of 93.5% and switching frequency of 170kHz. Wide operating temperature range from -40°C to +85°C.
Includes remote On/Off and protection features for safer operations. Isolation voltage of 1kV AC enhances safety in system design. Lightweight and compact for space-constrained applications. Discover more DC/DC Converters from Cosel and explore advanced power supply solutions in the Electronics & Electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum output power of this model is 202.5W.
It provides a stable output voltage of 15V DC.
This unit accepts a wide input voltage range from 18V to 24V DC.
It supports a maximum output current of 13.5A.
The dimensions of this model are 58.9mm in length, 12.7mm in width, and 12.7mm in depth.
It operates with an efficiency of 93.5%.
The maximum switching frequency is 170kHz.
Yes, it includes overcurrent and overvoltage protection features.
This converter is designed for PCB mounting and comes in a DIP package.
It operates reliably across a temperature range from -40°C to +85°C.
The isolation voltage is 1kV AC.
The country of origin for this model is Japan.
