XP Power AH DC/DC Converter, 500V DC Output, 3mA Current, 12V DC Input, Through Hole Mount, 1.5W Power, Operating AH05N-12

XP Power AH05N-12 DC/DC Converter is a high-quality isolated power converter designed to deliver 500V DC output with an output current of 3mA from a 12V DC input supply. It is constructed using a through-hole mount type package to facilitate easy installation on printed circuit boards and supports operation within a temperature range of -25°C to 75°C, making it suitable for challenging industrial environments.

The converter offers a power rating of 1.5W and features galvanic isolation with an isolation voltage of 500V, providing electrical safety and signal integrity. With low output/input capacitance and proportional input/output characteristics, this converter minimizes noise and ripple to 0.7% peak-to-peak, ensuring reliable operation in sensitive measurement and control applications.

Designed with high reliability, the unit carries an MTBF of approximately 1,862,000 hours, and includes protective features such as 1-minute minimum short circuit protection and no minimum load requirement, thus enhancing longevity and system stability. External components are not required, simplifying circuit design and reducing overall system cost.

This converter is ideal for use in industrial, laboratory, and scientific equipment including avalanche photodiodes, photomultiplier tubes, piezoelectric devices, electrophoresis equipment, mass spectrometry, sustaining ion pumps, and capacitor charging applications. Its compact size, with dimensions 23.37 mm in length, 11.43 mm in width, and 6.35 mm in depth, supports space-constrained designs.

Manufactured in the United States, the XP Power AH05N-12 ensures compliance with RoHS standards. The product is supplied as new and ready for deployment in demanding professional environments.

This DC/DC converter provides isolated high-voltage output from low-voltage inputs. Strong galvanic isolation protects control electronics and enhances safety. Low ripple and noise preserve signal quality in precision applications.

Robust operating temperature range supports industrial and laboratory use. Compact through-hole package enables easy PCB mounting and space savings. High MTBF certifies long-term reliability under continuous operation. Designed for avalanche photodiodes, mass spectrometry, and related uses.

No minimum load requirement simplifies system design. Explore more DC/DC Converters and power supply components at EnvMart for your high-performance and reliable power conversion needs.
