Bourns 5040 Shielded Wirewound Surface Mount Inductor with Ferrite Core 22 μH ±20% 1.4 A Idc Q:17 SRN5040

Free Delivery in India | Lowest Global Shipping Charges

Bourns 5040 Shielded Wirewound Surface Mount Inductor with Ferrite Core 22 μH ±20% 1.4 A Idc Q:17 SRN5040

Name: Bourns 5040 Shielded Wirewound Surface Mount Inductor with Ferrite Core 22 μH ±20% 1.4 A Idc Q:17 SRN5040
Brand: BOURNS
SKU: 395694
Price: 0.31 USD
Availability: InStock



Category Surface Mount Inductor Brand BOURNS Condition New

Specifications

Country of Origin	India
Brand	Bourns
Height	4mm
Length	5mm
Model	SRN5040
Depth	5mm
Packaging	Reel
Series	SRN5040
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Core Material	Ferrite
Inductance Range	1.5 to 47 μH
Inductance	22μH
Standards/Approvals	RoHS
Package/Case	5040
Maximum DC Current	1.4A
Pin Count	2
Maximum DC Resistance	152mΩ
Inductance Tolerance	±20 %
Termination Style	Solder
Maximum Self Resonant Frequency	11MHz
Minimum Quality Factor	17
Inductor Construction	Wirewound

Key Features

The inductor has a semi-shielded construction enhancing magnetic performance.
Constructed with a ferrite core and wirewound inductor construction.
Designed for a maximum operating temperature of 125°C and minimum of -40°C.
It provides a low DC resistance of 152 mΩ and a quality factor of 17.
Packaged in a 5040 reel suitable for automated insertion.
Ideal for applications in DC/DC converters, notebook computers, and digital video cameras.
RoHS compliant and features solder termination style.
Compact dimensions with 5 mm length, 5 mm depth, and 4 mm height.

Product Description

Bourns SRN5040 5040 Shielded Wirewound Surface Mount Inductor with a ferrite core offers inductance of 22 μH ±20% with a rated current of 1.4 A, suitable for precision electronic circuits and power management applications.

This inductor series features a semi-shielded construction that minimizes electromagnetic interference while maintaining high efficiency. Its wirewound construction on a ferrite core ensures stable inductance and current handling capability.

Designed for surface mount technology, the component is ideal for automated PCB assembly processes, packaged on reels for ease of manufacturing integration.

The SRN5040 series supports operating temperature ranges from -40°C to 125°C, making it suitable for industrial, electronic, and consumer device applications including DC/DC converters, notebook computers, digital video cameras, hard disk drives, televisions, and LCD displays.

The low DC resistance of 152 mΩ results in minimal power loss, enhancing overall device efficiency. The quality factor (Q) of 17 at the rated frequency assures stable reactive performance in signal filtering and noise suppression.

The inductor has a semi-shielded construction enhancing magnetic performance. Constructed with a ferrite core and wirewound inductor construction. Designed for a maximum operating temperature of 125°C and minimum of -40°C.

It provides a low DC resistance of 152 mΩ and a quality factor of 17. Packaged in a 5040 reel suitable for automated insertion. Ideal for applications in DC/DC converters, notebook computers, and digital video cameras. RoHS compliant and features solder termination style.

Compact dimensions with 5 mm length, 5 mm depth, and 4 mm height. Bourns inductors are widely used across industrial, laboratory, electronic manufacturing, and telecommunications sectors for reliable and efficient inductive components.

Explore more advanced inductors and electronic components through EnvMart's comprehensive electronic component catalog.
